ABB PFTL201C-10KN 3BSE007913R0010 Load Cells

ABB PFTL201C-10KN 3BSE007913R0010 Load Cells

Product core positioning

ABB PFTL201C-10KN 3BSE007913R0010 is a high-precision strain type weighing sensor in the field of industrial weighing and force measurement. Its core function is to convert physical load signals into transferable electrical signals, providing accurate weight data support for material measurement, process control, safety monitoring and other scenarios. It belongs to the ABB industrial weighing sensor series and is widely compatible with weighing systems in automated production lines, warehousing and logistics, and process industries. It is a key sensing component for achieving digital weight control.

Key technical parameters

Measurement ability

Rated load 10KN (1000kgf), measurement range 0-12KN (overload 20%)

Accuracy level

OIML C3 level (compliant with the International Organization for Legal Metrology standards), non-linear error ≤± 0.02% F.S

Signal output

Analog signal: 2mV/V (under excitation voltage), supporting 10-15V DC excitation power supply

Hardware interface

4-wire cable output (power positive, power negative, signal positive, signal negative), protection level IP67

Environmental adaptability

Working temperature -30 ° C to 80 ° C, temperature compensation range -10 ° C to 60 ° C, excellent anti vibration and impact performance

Physical specifications

The material is stainless steel (316L), with slight differences in size depending on the installation form. It supports flange and bolt fixation

Compatibility

Compatible with ABB CI858-1 communication module, AC 800M controller, and System 800xA control system

Core functions and advantages

1. High precision and stability design

By adopting a strain gauge bridge structure and combining it with laser welding technology, the linearity and repeatability of load signal conversion are ensured to meet the requirements of precision measurement.

Built in temperature compensation circuit effectively offsets the influence of environmental temperature changes on measurement results, and can maintain an accuracy deviation of ± 0.01% F.S. under high and low temperature conditions.

2. Industrial grade durability

The stainless steel shell has an IP67 protection level, which can resist dust, water vapor, and mild corrosion, and is suitable for dusty or humid environments such as food processing and chemical industry.

The mechanical structure has undergone fatigue testing and can withstand over 1 million rated load cycles, with an MTBF (mean time between failures) exceeding 100000 hours.

3. Convenience of system integration

Standardized 4-wire output interface, which can be connected to weighing transmitters, PLCs, and communication modules without the need for dedicated adapters, simplifying the wiring process.

Supporting parallel use of multiple sensors, signal aggregation and remote transmission are achieved through ABB CI858-1 module, suitable for multi-sensor scenarios such as large material tanks and platform scales.
