Description

ABB REF615E_E (model designation HBFHAEAGNCA1BNN1XE) is a high-precision power system protection and control module designed specifically for the safe operation of medium and low voltage distribution networks. Its core function is to perform real-time monitoring, fault protection, and logic control of equipment such as transformers, motors, and feeders in the distribution system. By accurately collecting electrical parameters such as current, voltage, and power, it can quickly identify abnormal working conditions such as short circuits, overloads, and grounding faults, and trigger protective actions such as tripping and alarms. At the same time, it supports remote control and data communication, and is a key component to ensure the stable and reliable operation of medium and low voltage distribution systems. This module is widely applicable to industrial enterprise distribution systems, commercial building distribution networks, new energy power station auxiliary distribution systems, and other scenarios, especially suitable for power systems with strict requirements for protection accuracy, response speed, and communication compatibility.




ABB REF615E_E HBFHAEAGNCA1BNN1XE Module

Product core positioning

ABB REF615E_E (model designation HBFHAEAGNCA1BNN1XE) is a high-precision power system protection and control module designed specifically for the safe operation of medium and low voltage distribution networks. Its core function is to perform real-time monitoring, fault protection, and logic control of equipment such as transformers, motors, and feeders in the distribution system. By accurately collecting electrical parameters such as current, voltage, and power, it can quickly identify abnormal working conditions such as short circuits, overloads, and grounding faults, and trigger protective actions such as tripping and alarms. At the same time, it supports remote control and data communication, and is a key component to ensure the stable and reliable operation of medium and low voltage distribution systems. This module is widely applicable to industrial enterprise distribution systems, commercial building distribution networks, new energy power station auxiliary distribution systems, and other scenarios, especially suitable for power systems with strict requirements for protection accuracy, response speed, and communication compatibility.


Key technical parameters

1. Basic specifications

Model identification

REF615E_E HBFHAEAGNCA1BNN1XE

Complete model identification, including functional codes and configuration information, to ensure accurate product selection

Dimensions (W × H × D)

145mm×210mm×190mm

Compliant with standard installation dimensions for distribution cabinets, suitable for 19 inch cabinets or wall mounted installations, saving installation space

Weight

About 2.8kg

Adopting high-strength engineering plastic shell, balancing protective performance and installation convenience, single module can be independently fixed and installed

Protection level

IP40

Suitable for installation in power distribution rooms, effectively preventing dust and solid foreign objects from entering, and can resist slight dust pollution in the environment

Installation method

19 inch cabinet installation/wall mounted installation

Supports two installation methods, equipped with standardized installation brackets, reducing installation time by 40% compared to traditional modules


2. Electrical and protective characteristics

Power parameters:

Working power supply: DC 24V/48V/110V/220V or AC 110V/220V, supports wide voltage input, adapts to different power supply specifications of distribution systems

Power consumption: ≤ 15W during normal operation, ≤ 20W during protection action, low-power design reduces system operating costs

Analog quantity acquisition:

Current input: 4-channel three-phase current input (IA, IB, IC)+1-channel neutral line current input (IN), input range 0-5A (directly connected) or 0-1A (with current transformer), accuracy ± 0.1% FS

Voltage input: 3-channel three-phase voltage input (UA, UB, UC), input range 0-100V (line voltage or phase voltage, with voltage transformer), accuracy ± 0.1% FS

Frequency acquisition: Range 45-65Hz, accuracy ± 0.01Hz, capable of real-time monitoring of power grid frequency fluctuations

Protection function parameters:

Protection types: including overcurrent protection (quick break, timed limit, inverse time limit), overload protection, ground fault protection (zero sequence current protection), overvoltage protection, low voltage protection, frequency anomaly protection (over frequency/low frequency), CT disconnection detection, PT disconnection detection, etc

Protection response time: overcurrent quick break protection response time ≤ 20ms, ground fault protection response time ≤ 30ms, quickly cut off faults, reduce equipment damage and power outage range

Fixed value range: overcurrent fixed value 0.1-10Ie (Ie is rated current), overvoltage fixed value 1.05-1.5Un (Un is rated voltage), low voltage fixed value 0.5-0.95Un, fixed value adjustment accuracy ± 1%

Digital I/O:

Digital input: 8-channel passive dry contact input, used to receive external device status signals (such as circuit breaker position, cabinet door status), response time ≤ 1ms

Digital output: 6-way relay output (normally open/normally closed configurable), contact capacity AC 250V/5A or DC 30V/5A, can be used to control circuit breaker tripping/closing, drive alarm devices

Communication interface:

Supports multiple industrial communication protocols, including IEC 61850(MMS/GOOSE/SV)、Modbus RTU/TCP、DNP3.0、IEC 60870-5-101/103/104  Wait, wait

Equipped with 2 Gigabit Ethernet ports (RJ45 type, supporting network redundancy) and 1 RS485 serial communication port, with a maximum data transmission rate of 1Gbps and a communication delay of ≤ 50 μ s, meeting real-time data transmission and remote control requirements

3. Environmental adaptability

Working temperature: -25 ° C to 70 ° C, passing high and low temperature cycling tests (-25 ° C freezing for 4 hours → 70 ° C high temperature for 4 hours, cycling 30 times), with no degradation in protection function and acquisition accuracy

Storage temperature: -40 ° C to 85 ° C, meeting the extreme temperature requirements for long-term inventory and cross regional transportation

Relative humidity: 5% -95% (no condensation), moisture-proof treatment is used internally, and the PCB board is coated with a three proof coating (epoxy resin material), suitable for humid distribution environments (such as underground distribution rooms)

Anti interference: Complies with IEC 61000-6-2 (industrial electromagnetic interference) and IEC 61000-6-4 (radio frequency interference) standards, with 4kV electrical fast transient pulse group immunity and 8kV electrostatic discharge immunity. In strong interference environments with dense high-voltage equipment, the accuracy of protection actions is ≥ 99.9%

Vibration and impact: able to withstand sine vibration within the frequency range of 10-500Hz and acceleration of 1g; Capable of withstanding a peak acceleration of 10g and an impact duration of 11ms, suitable for vibration and transportation bumps during the operation of power distribution equipment


Core functions and advantages

1. Comprehensive protection and precise control

The module is equipped with a rich library of protection functions, which can flexibly configure protection logic and settings based on the fault characteristics of different equipment such as transformers, motors, and feeders in medium and low voltage distribution systems. For example, for motor loads, inverse time overcurrent protection and locked rotor protection can be enabled to accurately match the overload characteristics of the motor; For feeder circuits, quick break overcurrent protection and ground fault protection can be configured to quickly cut off short-circuit faults. At the same time, it supports online modification and solidification of protection settings, and can complete configuration updates without power outage, ensuring the continuity of system operation. In addition, the module has a protection action recording function, which can store the last 200 protection events (including fault type, fault parameters, and action time) with a resolution of 1ms, making it easy to analyze and trace faults.

2. High precision data collection and monitoring

Using a 16 bit high-precision ADC conversion chip and advanced signal conditioning circuit, real-time acquisition of electrical parameters such as current, voltage, power, and frequency is achieved with an accuracy of ± 0.1% FS, far exceeding the industry average level (± 0.5% FS). It can calculate and monitor electric energy parameters such as active power, reactive power, apparent power, power factor, and electric energy (active/reactive). The accuracy of electric energy measurement meets the IEC 62053-22 Level 1 standard, and can replace traditional electric energy meters to achieve accurate measurement and statistics of electric energy. At the same time, it supports real-time monitoring of the module's own operating status (such as power status, communication status, I/O status). When module abnormalities (such as power failure, communication interruption) are detected, local and remote alarms can be triggered to improve system operation and maintenance efficiency.


3. Flexible communication and remote operation and maintenance

Multi protocol compatibility: fully supports the IEC 61850 standard communication protocol, seamlessly integrates with intelligent distribution automation systems, and achieves standardized transmission of protection information, measurement data, and control instructions; Simultaneously compatible with mainstream protocols such as Modbus and DNP3.0, it facilitates integration with third-party SCADA systems, PLC devices, and human-machine interfaces (HMI), reducing system integration costs

Network redundancy: equipped with dual gigabit Ethernet ports, supporting network redundancy (such as ring network redundancy, dual network redundancy). When the main communication link fails, the backup link can be switched within 100ms to ensure uninterrupted communication and meet the high reliability communication requirements of critical power distribution systems

Remote control and operation: Supports remote control (such as remote tripping/closing of circuit breakers, remote modification of protection settings), remote parameter configuration, remote firmware upgrade, and fault diagnosis through communication networks. Operation and maintenance personnel can complete more than 90% of maintenance work without the need to be on site, especially suitable for operation and maintenance management of decentralized distribution networks (such as power distribution systems in multiple buildings in industrial parks)

4. High reliability and ease of use

Hardware reliability: industrial high stability electronic components (such as military grade capacitors and anti-aging resistors) are used, and key circuits (such as power supply circuits and protective outlet circuits) are designed with dual redundancy. After strict environmental adaptability tests (high and low temperature, humidity, vibration, shock) and long-term aging tests, the mean time between failures (MTBF) exceeds 150000 hours to ensure long-term stable operation

Software security: It has a comprehensive software anti misoperation mechanism, and the protection of fixed value modifications requires authorization password verification. Remote control operations require double confirmation to prevent protection misoperation or refusal caused by misoperation; Simultaneously supporting software log recording, all operation records (such as fixed value modification and control operations) can be traced, facilitating security auditing

Usability design: The module is equipped with a 3.5-inch color touch screen on the front, which can intuitively display electrical parameters, protection status, and fault information. It supports touch operation for local parameter configuration and control; Simultaneously equipped with LED indicator lights (power indicator light, operation indicator light, fault indicator light, communication indicator light), which can quickly determine the operation status of the module and facilitate on-site operation and maintenance personnel to troubleshoot problems
