  • THQD32125WL | General Electric Molded Case Circuit Breaker
    ❤ Add to collection
  • THQD32125WL | General Electric Molded Case Circuit Breaker

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia
    THQD32125WL | General Electric Molded Case Circuit Breaker
    • ¥7289.00
      ¥84921.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:2.500KG
    • Quantity:
    • (Inventory: 3)
Description
THQD32125WL | General Electric Molded Case Circuit Breaker

THQD32125WL | General Electric Molded Case Circuit Breaker

Product Description P/N: THQD32125WL Description / Specifications Description The THQD32125WL is a General Electric Q-Line molded case circuit breaker, classified as Type THQD. It is a three-pole (3P), three-phase (3PH) device rated at 125 amperes (125A) with a voltage rating of 240 volts (240V). The circuit breaker features a high interrupting capacity of 22 kiloamperes at 240 volts (22kA@240V). It includes a non-interchangeable trip unit and is equipped with line and load side lug terminals.

Designed for thermal magnetic operation, it is suitable for feed-thru installations and is rated for use in environments with an ambient temperature of up to 40 degrees Celsius. Technical Specifications Part Number THQD32125WL Manufacturer General Electric Family Q-Line Pole 3 Amp 125 Volt 240 Phase 3 Category Molded Case / 3-Pole Connection Feed-Thru Type THQD Functions LI - Long-Time and Instantaneous Protection Thermal Magnetic AIC Ratings 22kA@240V Information About THQD32125WL

 The THQD32125WL is a molded case circuit breaker manufactured by General Electric, specifically designed as part of the Q-Line family. This circuit breaker is designated as Type THQD and is characterized by its three-pole (3P) configuration, suitable for three-phase (3PH) electrical systems. It is rated for a current capacity of 125 amperes (125A) and is capable of operating at a voltage of 240 volts (240V). The device features a high interrupting capacity, rated at 22 kiloamperes at 240 volts (22kA@240V).

 The THQD32125WL circuit breaker incorporates a non-interchangeable trip unit, which ensures that the trip settings are fixed and cannot be modified or replaced. This unit is equipped with both line and load side lug terminals, facilitating secure connections for both incoming and outgoing circuits. The circuit breaker is designed for feed-thru connection, allowing it to be easily integrated into existing electrical distribution systems. Manufacturer information General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power.

GE is known for its innovations in technology, manufacturing, and infrastructure solutions. IQElectro is not an authorized distributor. QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply.IQElectro sells SURPLUS onlyand DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.

Features

 Complete Analog subsystem includes Base Converter and Expander modules

 Base Converter module has eight differential inputs individually configurable for voltage or current

 Accepts unipolar or bipolar Analog Inputs up to " 10 volts full scale

 Accepts 4 to 20 milliamp current loop signals

 Individual user scaling on each input channel on Base Converter module; scaling on a per module basis for Expander modules

 Fast update rate for Base Converter module

 Voltage and current Expander modules, each with 16 inputs, provides for additional inputs at a lower cost per point

 Complete subsystem can accept up to 120 inputs

 No jumpers or DIP switches to configure

 Easy configuration with MS-DOS

or Windows

 programming software configuration function.
