  • GE WEA13-13 2508-21001 Embedded Digital Module
    ❤ Add to collection
  • GE WEA13-13 2508-21001 Embedded Digital Module

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    This module is a specialized digital processing module developed by GE for industrial embedded systems, integrating multiple functions such as signal acquisition, digital computation, and data transmission. It adopts standardized hardware interfaces and modular design, and can be quickly embedded into various industrial control equipment and monitoring terminals to achieve digital processing and intelligent control of on-site signals.

    -Product model: GE WEA13-13 2508-21001

    -Product Type: Embedded Digital Signal Processing Module

    -Core positioning: Industrial grade on-site signal digital conversion and real-time processing

    -Applicable fields: industrial automation control, power energy monitoring, intelligent manufacturing equipment, rail transit signal processing, etc


    • ¥23643.00
      ¥24574.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:1.056KG
    • Quantity:
    • (Inventory: 99999)
Description

This module is a specialized digital processing module developed by GE for industrial embedded systems, integrating multiple functions such as signal acquisition, digital computation, and data transmission. It adopts standardized hardware interfaces and modular design, and can be quickly embedded into various industrial control equipment and monitoring terminals to achieve digital processing and intelligent control of on-site signals.

-Product model: GE WEA13-13 2508-21001

-Product Type: Embedded Digital Signal Processing Module

-Core positioning: Industrial grade on-site signal digital conversion and real-time processing

-Applicable fields: industrial automation control, power energy monitoring, intelligent manufacturing equipment, rail transit signal processing, etc





GE WEA13-13 2508-21001 Embedded Digital Module

Basic information of module

This module is a specialized digital processing module developed by GE for industrial embedded systems, integrating multiple functions such as signal acquisition, digital computation, and data transmission. It adopts standardized hardware interfaces and modular design, and can be quickly embedded into various industrial control equipment and monitoring terminals to achieve digital processing and intelligent control of on-site signals.

-Product model: GE WEA13-13 2508-21001

-Product Type: Embedded Digital Signal Processing Module

-Core positioning: Industrial grade on-site signal digital conversion and real-time processing

-Applicable fields: industrial automation control, power energy monitoring, intelligent manufacturing equipment, rail transit signal processing, etc


Core functional characteristics

This module is designed with the core concept of "high precision, high stability, and strong adaptability", and has the following functional characteristics to meet the demanding requirements of complex industrial scenarios:

1. Multi type signal acquisition and digital conversion

Supports synchronous acquisition of analog signals (such as 4-20mA current signals, 0-10V voltage signals) and digital signals (switch signals, pulse signals), with built-in high-precision AD converter, conversion accuracy up to 16 bits, and sampling rate up to 1kHz. It can quickly convert on-site analog signals into accurate digital signals, providing a reliable data foundation for subsequent processing. At the same time, the module has signal filtering function, which can effectively suppress electromagnetic interference in industrial sites and reduce signal noise.

2. Real time digital computation and logic control

Equipped with high-performance embedded microprocessors, it has powerful real-time computing capabilities and can achieve various digital computing functions such as data calibration, threshold judgment, and cumulative calculation. It supports user-defined simple logic control rules and can complete basic control decisions without relying on the upper computer, improving system response speed. For example, in the scenario of power monitoring, the effective values of voltage and current can be calculated in real time, and whether they exceed the set threshold can be determined, and alarm signals can be output in a timely manner.

3. Flexible communication interface and data transmission

Equipped with rich communication interfaces, including RS485, CAN bus, and Ethernet interfaces (some models), supporting mainstream industrial communication protocols such as Modbus and Profinet, it can seamlessly interface with various control devices such as PLC, DCS, and industrial upper computer, achieving bidirectional data transmission. The module supports data caching function. When communication is interrupted, critical data can be temporarily stored and automatically replenished after connection is restored to ensure data integrity.

4. Industrial grade reliability and environmental adaptability

Adopting industrial grade components and reinforced casing design, it has a wide temperature working range (-40 ℃~85 ℃) and can adapt to harsh industrial environments such as high temperature, low temperature, and humidity; The module has overvoltage, overcurrent, and short-circuit protection functions, which can effectively prevent external circuit faults from damaging the module. The mean time between failures (MTBF) exceeds 100000 hours, ensuring long-term stable operation of the system.

5. Convenient configuration and debugging functions

Support parameter configuration through GE dedicated configuration software or upper computer instructions, allowing for flexible setting of key parameters such as signal acquisition range, sampling rate, communication parameters, alarm thresholds, etc; The module has built-in self diagnostic function, which can monitor its own working status in real time (such as power supply voltage, communication status), and feedback fault information through specific signals, making it easy for technicians to quickly locate and troubleshoot problems.


Key technical parameters

Power parameters

Working Voltage

DC 12V~24V, Allow ± 10% fluctuation

rated current

≤ 300mA (without external load)

power protection

Overvoltage, overcurrent, and reverse connection protection

Parameter collection

Analog input

4-channel differential input, supporting 4-20mA/0-10V

Digital input

8-way dry contact input, supporting NPN/PNP compatibility

AD conversion accuracy

16 bits

sampling rate

10Hz~1kHz, configurable

Communication parameters

communication interface

1 RS485, 1 CAN bus, 1 Ethernet (RJ45)

Supported Protocols

Modbus RTU/TCP,Profinet,CANopen

communication rate

RS485:9600~115200bps; Ethernet: 10/100Mbps adaptive

environmental parameters

Operating Temperature

-40℃~85℃

relative humidity

5%~95%, no condensation

Protection level

IP20 (module itself), the protection level after installation depends on the casing

physical parameters

size

65mm x 45mm x 18mm (length x width x height), compatible with standard DIN rail installation


Typical application scenarios

This module has been widely used in multiple industrial fields due to its excellent performance. The following are typical scenario examples:

1. Industrial automation control system

A remote I/O unit embedded in a PLC or distributed control system (DCS) collects sensor signals such as temperature, pressure, and flow on the production line, processes them digitally, and transmits them to the control core. At the same time, it receives control instructions, drives actuator actions, and achieves closed-loop control of the production process. For example, in chemical production, real-time pressure signals from reaction vessels are collected and fed back to the PLC through module calculations to accurately adjust the opening of the feed valve.

2. Power energy monitoring system

Used for monitoring electrical parameters in substations, photovoltaic power stations, and other scenarios, collecting signals such as voltage, current, power, and power factor, and transmitting them to the energy management platform through CAN bus or Ethernet to achieve power quality analysis, energy consumption statistics, and abnormal alarm functions, providing data support for energy optimization and scheduling.

3. Intelligent manufacturing equipment

Integrated into intelligent manufacturing equipment such as CNC machine tools and robots, it collects equipment operating status signals (such as motor speed, spindle temperature, vibration signals), performs real-time calculations and logical judgments, and outputs a shutdown signal in a timely manner when abnormalities are detected to ensure the safe operation of the equipment. At the same time, the operating data is uploaded to the MES system to achieve intelligent management of equipment operation and maintenance.

4. Rail Transit Signal Processing

In the field of rail transit, it is used for monitoring the operation status of trains or processing track signals, collecting the speed, position, and track circuit signals of trains, and transmitting the data to the train control system through highly reliable communication interfaces to ensure the safety and stability of train operation.


Precautions for use

-Installation specifications: It should be installed in an environment with good ventilation, no severe vibration, and strong electromagnetic interference, avoiding close placement with high-voltage equipment or high-power motors; When installing with DIN rails, it is necessary to ensure a secure installation to prevent module loosening and poor contact.

-Wiring requirements: strictly follow the module pin definition for wiring, and the positive and negative poles of the power supply cannot be reversed; Analog input and digital input lines need to be wired separately to avoid signal interference; The communication line needs to use shielded wire and be properly grounded, with a grounding resistance of ≤ 4 Ω.

-Parameter configuration: Before first use, parameter initialization must be completed through configuration software to ensure that the collection range, communication protocol, and other parameters are consistent with system requirements; After modifying the parameters, the module needs to be restarted to ensure that the parameters take effect.

-Maintenance: Regularly check whether the module wiring is loose and whether the housing is damaged; In high temperature and high humidity environments, it is necessary to strengthen the frequency of equipment inspections to avoid module failure due to environmental factors; Do not plug or unplug wiring while the module is powered on to avoid module damage.

-Fault handling: If the module has no response, abnormal data or other faults, you can first check the fault code through the self diagnostic function, and then sequentially investigate the power supply, wiring, communication links and other links; If the fault cannot be resolved, please contact GE's official technical support and do not disassemble the module without authorization.
