  • GE 208D9845P0008 Motor Management Relay
    ❤ Add to collection
  • GE 208D9845P0008 Motor Management Relay

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    This relay belongs to the GE industrial motor protection product series and is an intelligent device upgraded and developed to address the problems of single function and insufficient accuracy of traditional motor protection devices. The "208D" in the model is the core series identification of GE motor protection relays, indicating their digital and multifunctional product characteristics; 9845P0008 "is a product specific model code that covers key information such as protection function configuration, interface specifications, firmware versions, etc., ensuring compatibility with motor systems in different industrial scenarios.

    • ¥14357.00
      ¥16347.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:0.460KG
    • Quantity:
    • (Inventory: 99999)
Description

This relay belongs to the GE industrial motor protection product series and is an intelligent device upgraded and developed to address the problems of single function and insufficient accuracy of traditional motor protection devices. The "208D" in the model is the core series identification of GE motor protection relays, indicating their digital and multifunctional product characteristics; 9845P0008 "is a product specific model code that covers key information such as protection function configuration, interface specifications, firmware versions, etc., ensuring compatibility with motor systems in different industrial scenarios.




GE 208D9845P0008 Motor Management Relay

Basic Overview of Relays

This relay belongs to the GE industrial motor protection product series and is an intelligent device upgraded and developed to address the problems of single function and insufficient accuracy of traditional motor protection devices. The "208D" in the model is the core series identification of GE motor protection relays, indicating their digital and multifunctional product characteristics; 9845P0008 "is a product specific model code that covers key information such as protection function configuration, interface specifications, firmware versions, etc., ensuring compatibility with motor systems in different industrial scenarios.

In the motor control system, this relay plays a dual role as a "safety guard and control node": on the one hand, it collects real-time motor operating parameters through sensors such as current, voltage, and temperature, and uses built-in algorithms to determine whether the motor is in abnormal working conditions such as overload, overcurrent, phase loss, and locked rotor. When the protection threshold is reached, it quickly triggers a trip or alarm action; On the other hand, it receives control instructions from upper level controllers (such as PLC, DCS) to achieve control functions such as motor start stop and forward/reverse switching. At the same time, it uploads motor operation status data to the monitoring system to provide data support for operation and maintenance management.


Core performance parameters

The performance parameters of GE 208D9845P0008 motor management relay directly determine the accuracy of motor protection and the reliability of control. The following is a detailed explanation of key technical indicators:

1. Adapt to motor specifications and measurement range

The relay can adapt to three-phase asynchronous motors, synchronous motors, and single-phase motors with a power range of 0.75kW-1000kW. It supports various specifications of motors with rated voltages of AC 220V, 380V, 660V, 1140V, etc., and adapts to frequencies of 50Hz/60Hz. Core electrical parameter measurement range coverage: ① Current measurement, 0.1A-1000A (adapted to different ranges through external current transformers, transformer ratio can be configured through software); ② Voltage measurement, 0-1200V (line voltage/phase voltage switchable); ③ Power measurement, 0-1000kW (active power, reactive power, apparent power); ④ Temperature measurement, -40 ℃ -200 ℃ (supports PTC, PT100, and thermocouple inputs).

2. Measurement accuracy and response speed

-Measurement accuracy: The current measurement accuracy is ± 0.5% FS, the voltage measurement accuracy is ± 0.5% FS, the power measurement accuracy is ± 1% FS, the temperature measurement accuracy is ± 1 ℃, and the frequency measurement accuracy is ± 0.1Hz, ensuring accurate monitoring of motor operating parameters and providing reliable basis for protection and control.

-Response speed: The response time for serious fault protection such as overcurrent and short circuit is ≤ 10ms, and the response time for locked rotor and phase loss faults is ≤ 50ms. The response time for overload protection can be adaptively adjusted according to the overload factor (the larger the overload factor, the faster the response), and can reach up to 100ms at the fastest. It can quickly cut off the fault circuit and minimize motor damage.

3. Protection function and threshold configuration

It has more than 20 types of motor specific protection functions, covering the risk points of the entire life cycle of motor operation. The core protection functions and configurable thresholds are as follows: ① Overload protection, the overload multiple threshold can be set to 1.05-6.0 times the rated current, and the protection curve supports two modes: inverse time limit (in accordance with IEC 60947-4-1 standard) and definite time limit; ② Short circuit protection, threshold can be set to 3.0-10.0 times rated current, using instantaneous tripping mode; ③ Phase loss protection, triggered when any phase current is below the set threshold (5% -50% rated current); ④ Locked rotor protection, the locked rotor current threshold can be set to 1.5-8.0 times the rated current, with a delay time of 0.1-10s; ⑤ Overvoltage/undervoltage protection, the voltage threshold can be set to 70% -130% of the rated voltage; ⑥ Temperature protection, the temperature threshold can be set between 40 ℃ and 180 ℃ (configured according to the insulation level of the motor); ⑦ Unbalance protection, the threshold for phase current imbalance can be set at 5% -30%. All protection thresholds support flexible configuration through software or panel buttons, adapting to the protection requirements of different motors.

4. Control functions and output interfaces

Supports multiple motor control modes, including direct start control, star delta start control, auto coupling voltage reduction start control, soft starter linkage control, etc., to meet the starting needs of motors of different powers. Rich output interface configuration: ① Relay output, 6-way normally open/normally closed configurable contacts, contact capacity AC 250V/10A or DC 30V/5A, used for controlling contactors, circuit breakers, alarm devices, etc; ② Analog output, 2-channel 4-20mA current signal, capable of outputting motor current, power and other parameters to PLC or HMI; ③ Pulse output, 1-channel frequency signal, used for scenarios such as energy metering.

5. Communication and data interaction capabilities

Equipped with comprehensive communication interfaces, supporting multiple industrial communication protocols, including 1 RS485 interface (supporting Modbus RTU protocol) and 1 Ethernet interface (supporting Modbus TCP, EtherNet/IP protocol, communication rate adaptive to 10/100Mbps), it can achieve high-speed data exchange with upper monitoring systems (such as SCADA, PLC), HMI, and energy management systems. Support functions such as uploading motor operating parameters, uploading protection event records, receiving remote control commands, and remotely configuring protection thresholds. The data transmission delay is ≤ 50ms, meeting the requirements of centralized monitoring and remote operation and maintenance.

6. Environmental adaptability and power specifications

Designed for complex industrial environments, with excellent environmental adaptability: the working temperature range is -25 ℃~70 ℃, which can adapt to extreme temperature scenarios such as high-temperature workshops and outdoor distribution boxes; The relative humidity range is 5%~95% (no condensation), and it can operate stably in humid chemical workshops or rainy season environments; It has an IP54 protection level (body) and supports direct installation in the motor control cabinet, with good dust-proof and splash proof performance. The power input range is AC 85V~265V or DC 110V~300V, with a wide voltage design suitable for different industrial power supply systems. The typical power consumption is ≤ 10W, and it has overvoltage, undervoltage, and short-circuit protection functions. It can work stably when the power supply fluctuates.


Functional features and advantages

1. Combination of comprehensive protection and precise control

Compared to traditional single protection devices such as thermal relays and circuit breakers, this relay integrates multiple protection functions such as overload, short circuit, phase loss, and temperature, achieving "full dimensional" protection for motors and avoiding motor damage caused by the failure of a single protection. At the same time, by integrating functions such as start-up control and operation regulation, there is no need to configure additional control modules, simplifying the architecture of the motor control system and reducing equipment costs and wiring complexity. The protection and control logic are closely linked, for example, when the motor starts, the locked rotor protection threshold is automatically raised to avoid accidental tripping during the starting process, and the normal threshold is automatically restored after the start is completed, balancing the reliability of starting and the safety of operation.

2. Digital monitoring and intelligent diagnostic capabilities

By using digital signal processing technology, 16 operating parameters of the motor, including current, voltage, power, temperature, etc., are monitored in real time and displayed intuitively on an LCD screen. Parameter trend curve queries (parameter changes in the past 10 minutes) are supported. Equipped with intelligent diagnostic function, it can automatically identify sensor faults, communication faults, self circuit faults, etc., with diagnostic accuracy reaching component level. When a fault occurs, the fault code and description are immediately displayed on the display screen and uploaded to the upper system, making it easy for operation and maintenance personnel to quickly locate the problem. The built-in energy metering function can accumulate the active and reactive energy consumed by the motor, providing data support for energy management and cost accounting.

3. Flexible configuration methods and ease of use

Supports three configuration methods to meet different scenario requirements: ① Local configuration, directly setting protection thresholds, control parameters, communication parameters, etc. through the four function buttons on the relay panel and the 2.4-inch LCD display screen, with intuitive and convenient operation, without the need to connect to a computer; ② Software configuration, connected to a computer through GE specific configuration software (such as Motor Management Studio), enables batch parameter configuration and custom programming of control logic (supporting ladder diagram programming); ③ Remote configuration, using Ethernet or RS485 interface to remotely modify parameters from the upper system, suitable for centralized configuration of large-scale motor groups. Equipped with a bilingual display interface in Chinese/English, which can be switched according to needs to improve operational convenience.

4. Powerful event recording and tracing capabilities

Built in large capacity memory, capable of storing three types of event records: ① Protection event record, storing the last 200 protection action information, including event type, trigger time, motor parameters (current, voltage, temperature, etc.) at the time of action, with recording accuracy of milliseconds; ② Operation event record, storing the last 100 user operation information (such as parameter modification, manual start stop); ③ Fault diagnosis record, storing the last 50 fault information. All records will not be lost after power failure, making it easy for operation and maintenance personnel to trace the cause of motor faults, analyze fault patterns, and develop targeted maintenance strategies.

5. High reliability and long service life

Adopting industrial grade components and reinforced circuit design, the core chip uses a high anti-interference 32-bit microprocessor, and the signal acquisition circuit has photoelectric isolation and EMC filtering functions. The isolation voltage reaches 2500V AC/1min, which can resist electromagnetic interference and surge impact in industrial sites (supporting ± 2kV surge protection), ensuring stable operation in strong interference environments such as frequency converters and high-voltage equipment. The relay output contacts are made of silver alloy material, with a mechanical life of 1 million cycles and an electrical life of 100000 cycles, and an average time between failures (MTBF) of ≥ 300000 hours, meeting the long-term continuous operation needs of industrial motors.

6. Good compatibility and scalability

It is seamlessly compatible with GE's full range of motor control products, such as contactors, soft starters, and frequency converters, and supports interconnection with third-party brands of PLCs, sensors, and actuators. It achieves cross brand equipment collaboration through standard communication protocols. Adopting modular design and equipped with expansion interfaces, temperature acquisition modules, switch input expansion modules, communication expansion modules, etc. can be added according to needs to achieve flexible expansion of functions and adapt to motor control systems of different complexities.


Typical application scenarios

The GE 208D9845P0008 motor management relay, with its comprehensive protection function, precise control performance, and strong environmental adaptability, has been widely used in motor systems in multiple industrial fields. Typical scenarios include:

1. Manufacturing workshop: used for motor protection and control of equipment such as machine tools, injection molding machines, conveyors, fans, water pumps, etc. For example, in CNC machine tool motors in automotive parts processing plants, relays monitor motor current and temperature in real time. When overload or overheating occurs, immediate tripping protection is provided to avoid damage to machine tools and scrap of processed parts; In the conveyor motor of the assembly line, phase loss protection and imbalance protection are used to prevent the motor from burning out due to wiring faults, ensuring the continuous operation of the assembly line.

2. Power industry: Used for auxiliary motor control in thermal power plants and hydropower stations, such as motors for feedwater pumps, induced draft fans, and forced draft fans. Relays provide multiple protections such as overload, locked rotor, and temperature to ensure stable operation of auxiliary motors and avoid unit shutdown caused by auxiliary faults; At the same time, the motor status is uploaded to the power plant DCS system through the communication interface to achieve centralized monitoring.

3. Petrochemical industry: In the reaction kettle stirring motor and conveying pump motor of refineries and chemical plants, relays not only provide conventional overcurrent and phase loss protection, but also adapt to power grid fluctuations in chemical workshops through overvoltage/undervoltage protection. Temperature protection is used to monitor the insulation status of motors, prevent motor fires caused by high temperatures, and ensure chemical production safety.

4. Construction and HVAC industry: Used for motors such as chillers, cooling tower fans, and supply and exhaust fans in central air conditioning systems. Relays reduce the impact of motor starting current on the power grid through star delta start control function, extend the service life of motors through overload protection and temperature protection, and provide data support for building energy consumption management through energy metering function.

5. Metallurgical industry: In the auxiliary motors of steel mills and blast furnace fans in steel plants, relays are designed with enhanced anti-interference and dust protection to ensure stable protection of motors under high load and high dust conditions. When the motor experiences stalling (such as steel jamming in the rolling mill), it quickly triggers trip protection to avoid serious damage to the motor and rolling equipment.
