GE IC693CPU374GP Advanced Programmable Logic Controller Module

GE IC693CPU374GP  Advanced Programmable Logic Controller Module

Processor Speed:20 MHz RAM:2 MB Flash Memory:4 MB Communication Ports:RS-485 (x2), Ethernet (1) Operating Voltage:24 VDC Power Consumption:2.8 A Dimensions:84 mm x 133 mm x 105 mm Weight:0.6 kg The GE IC693CPU374GP CPU Module is engineered for seamless integration into complex industrial control systems. It boasts a robust 40 MHz processor, ensuring rapid execution of sophisticated control algorithms. Equipped with 2 MB of RAM and 4 MB of Flash Memory, this module provides ample storage for applications and data retention, even during power outages.

 With support for both RS-485 and Ethernet interfaces, the IC693CPU374GP facilitates flexible communication across various industrial networks, enhancing system connectivity and data exchange. Featuring 16 Digital Inputs and 16 Digital Outputs, it offers versatile I/O control, crucial for monitoring and managing industrial processes. Its expandability up to 4 additional modules allows for customization to meet specific application requirements. Designed with reliability in mind, the IC693CPU374GP is built to withstand harsh industrial environments, ensuring continuous operation without interruption. Its compact yet durable form factor makes it suitable for space-constrained installations. The GE IC693CPU374GP CPU Module is designed for industrial automation, offering robust performance and reliability for various control applications.

Features

▪ Contains 10 Mbytes of battery-backed user memory and 10 Mbytes of non-volatile flash user  memory.

▪ Provides access to bulk memory via reference table %W.

▪ Configurable data and program memory.

▪ Programming in Ladder Diagram, C, Structured Text, and Function Block Diagram.

▪ Supports auto-located Symbolic Variables that can use any amount of user memory.

▪ Reference table sizes include 32Kbits for discrete %I and %Q and up to 32K words each for  analog %AI and %AQ.

▪ Supports Series 90-70 discrete and analog I/O, communications, and other modules. For a  list of modules supported, refer to the PACSystems RX7i Installation Manual, GFK-2223.

▪ Supports all VME modules supported by Series 90-70.

▪ Supports RX7i data monitoring over the web. Allows a combined total of up to 16 web server  and FTP connections.

▪ Supports up to 512 program blocks. Maximum size for a block is 128KB.

▪ Test Edit mode allows you to easily test modifications to a running program.

▪ Bit-in-word referencing.

▪ Battery-backed calendar clock.

▪ In-system upgradeable firmware.

▪ Three isolated serial ports: an RS-485 serial port, an RS-232 serial port, and an RS-232  Ethernet station manager serial port.

▪ The embedded Ethernet interface provides:

- Data exchange using Ethernet Global Data (EGD)

- TCP/IP communication services using SRTP

- Support for SRTP Channels, Modbus/TCP Server, and Modbus/TCP Client

- Full programming and configuration services

- Comprehensive station management and diagnostic tools

- Two full-duplex 10BaseT/100BaseT/TX (RJ-45 Connector) ports with an internal network  switch providing auto-negotiated network speed, duplex mode, and crossover detection.

- User-configurable Redundant IP address

- Time synchronization to SNTP time server on Ethernet network (when used with  Release 5.00 or later CPU module).
