  • ABB IT94-3 HESG440310R2 HESG112699/B controller
    ❤ Add to collection
  • ABB IT94-3 HESG440310R2 HESG112699/B controller

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

     IT94-3 ("IT" stands for Intelligent Terminal Controller, i.e. Intelligent Terminal Controller); The "94" symbol indicates control performance and I/O configuration level, which is higher than the entry-level IT92 series; 3 "represents 3 sets of expansion interfaces, supporting multi module expansion. Order numbers HESG440310R2 (main controller unit) and HESG112699/B (I/O expansion base and wiring accessories package) are compatible with ABB AC 800M, Advant OCS system, and third-party standard I/O modules (compliant with Modbus/Profibus protocol).

    • ¥6953.00
      ¥7573.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:5.160KG
    • Quantity:
    • (Inventory: 99999)
Description

 IT94-3 ("IT" stands for Intelligent Terminal Controller, i.e. Intelligent Terminal Controller); The "94" symbol indicates control performance and I/O configuration level, which is higher than the entry-level IT92 series; 3 "represents 3 sets of expansion interfaces, supporting multi module expansion. Order numbers HESG440310R2 (main controller unit) and HESG112699/B (I/O expansion base and wiring accessories package) are compatible with ABB AC 800M, Advant OCS system, and third-party standard I/O modules (compliant with Modbus/Profibus protocol).




ABB IT94-3 HESG440310R2 HESG112699/B controller

Core attributes and identification

Product type: Small and medium-sized distributed intelligent controller (belonging to ABB Advant Fieldbus series, focusing on small and medium-sized control scenarios in industrial sites, with signal acquisition, logical operation and local control capabilities, suitable for small-scale control needs such as single machine equipment and production line subunits, can be used as an edge control node for large DCS/PLC systems, or independently form small control systems)

Model decoding: IT94-3 ("IT" stands for Intelligent Terminal Controller, i.e. Intelligent Terminal Controller); The "94" symbol indicates control performance and I/O configuration level, which is higher than the entry-level IT92 series; 3 "represents 3 sets of expansion interfaces, supporting multi module expansion. Order numbers HESG440310R2 (main controller unit) and HESG112699/B (I/O expansion base and wiring accessories package) are compatible with ABB AC 800M, Advant OCS system, and third-party standard I/O modules (compliant with Modbus/Profibus protocol).

Physical specifications: Adopting a compact rail installation design, with dimensions of 120mm (width) x 180mm (height) x 75mm (depth), net weight of 1.5kg, plastic+metal hybrid shell (main plastic weight reduction, key interface metal reinforcement), compatible with 35mm standard DIN rail, can be embedded in small distribution boxes for installation, saving on-site space, especially suitable for equipment intensive workshop scenes.


Key technical parameters

Control performance

32-bit ARM Cortex-M4 processor, with a main frequency of 168MHz and a processing speed of 200 MIPS, supporting fixed-point and floating-point operations; Program storage 32MB Flash (expandable up to 128MB), data storage 8MB RAM (supports parity check)

Capable of independently running 64 control circuits and processing 256 I/O data, meeting the needs of small and medium-sized scenarios (such as temperature/pressure control of standalone equipment and linkage of production line subunits), with low computational power consumption (full load operation power consumption ≤ 8W)

I/O configuration and expansion

Built in 6-channel AI (4-20mA/0-10V, 16 bit resolution), 4-channel AO (4-20mA, 12 bit accuracy), 12 channel DI (24V DC, optoelectronic isolation), and 6-channel DO (24V DC/2A, transistor output); Supports 3 sets of expansion interfaces, can connect 4 I/O expansion modules (such as AI expansion card, DO expansion card), and can expand up to 128 I/O channels at most

Built in I/O covers the basic requirements of small and medium-sized scenarios, and the expansion interface supports "hot plugging". In the later stage, channels can be added as needed to avoid cost waste caused by excessive initial configuration

Communication capability

1 Gigabit Ethernet interface (supporting Modbus TCP, EtherNet/IP), 2 Profibus DP slave interfaces (adaptive rates of 1.5-12Mbps), 1 RS485 interface (supporting Modbus RTU for local debugging)

The communication interface is streamlined yet practical, with Gigabit Ethernet meeting the high-speed data exchange requirements with the main controller/cloud platform (latency ≤ 5ms), and dual Profibus DP supporting the connection of peripheral I/O modules, suitable for small and medium-sized system network architectures

Power supply demand

DC 24V ± 10%, rated power consumption of 8W, maximum power consumption of 15W (when expanding 2 I/O modules)

It can be powered centrally through the ABB SR511 power module or directly taken from the device's built-in 24V power supply. The low-power design is suitable for battery backup scenarios (such as temporary mobile control devices)

Working environment

Temperature -25 ℃ to+70 ℃, humidity 5% -95% (no condensation), protection level IP20 (needs to be matched with a distribution box to achieve IP65 protection)

Adapting to the conventional industrial workshop environment, if deployed outdoors or in high dust/humid areas, waterproof and dustproof distribution boxes need to be installed, compatible with the operating environment of most manufacturing and municipal facilities

Security and Certification

Compliant with IEC 61010-1 safety standard, with anti electromagnetic interference level IEC 61000-6-2 (Level 3), CE and UL certification

Satisfy ordinary industrial safety requirements, resist general electromagnetic interference (such as small motors and frequency converters), and adapt to control scenarios in non explosion proof and non extreme environments


Core functions and technological advantages

1. Precise control of small and medium-sized scenes

Lightweight logic operation: Supports IEC 61131-3 standard programming language (mainly ladder diagram LD, function block diagram FBD, simplified structured text ST), built-in commonly used control algorithms (standard PID, timing control, interlock logic), can achieve single machine equipment control without complex programming, such as injection molding machine temperature control (6-way AI collects temperature in each area, 4-way AO adjusts heating rod power), with a control accuracy of ± 0.5 ℃, meeting the process requirements of small and medium-sized equipment.

Efficient I/O management: Built in I/O channels support independent configuration (such as AI signal type switching, DI anti shake time setting, DO output mode selection), automatically isolate in case of channel failure, and do not affect the operation of other channels; Supports local caching of I/O data (cache capacity 1MB). When communication with the main controller is briefly interrupted, critical data within 5 minutes can be cached and automatically synchronized after recovery to avoid data loss.

Equipment linkage control: By connecting peripheral sensors and actuators through the Profibus DP interface, simple linkage of multiple devices can be achieved. For example, in packaging machine control, IT94-3 receives the product arrival signal from the photoelectric sensor (DI), controls the start and stop of the conveyor motor (DO), and adjusts the speed of the packaging film traction mechanism (AO). The response time is ≤ 10ms, ensuring packaging efficiency and accuracy.

2. Usability and operational convenience

Simplified programming and debugging: compatible with ABB Control Builder Mini software (lightweight version, installation package<100MB), built-in device control templates (such as motor control and temperature regulation templates), drag and drop configuration parameters, and can be debugged without professional programming knowledge; Support connecting handheld debuggers through RS485 interface for on-site parameter modification (such as PID settings and DI stabilization time), without the need to carry a computer.

Local status monitoring: The module is equipped with 16 LED indicator lights (corresponding to the built-in I/O channel status) and 1 monochrome LCD display screen (128 × 64 resolution, displaying operating mode, key I/O data, and fault codes) on the front. Operations personnel can intuitively view the channel working status, and when there is a fault, the fault code (such as "E01-AI1 over range") can be read through the display screen to quickly locate the problem.

Low cost deployment and expansion: Compact design reduces installation space requirements (saving 30% installation space compared to NF93A-2), with a single module cost of only 60% of NF93A-2; The unit price of the extended I/O module is low (about 500-800 US dollars per unit), and the deployment cost of small and medium-sized systems (I/O points ≤ 100) is 40% lower than that of large controllers, making it suitable for scenarios with limited budgets.

3. Reliability and compatibility

Basic fault protection: equipped with power overvoltage/overcurrent protection (automatically cuts off when 24V input exceeds 30V, triggers overload protection when output current exceeds 3A), I/O channel short circuit protection (automatically limits current when DO channel short circuit occurs to avoid module burnout); Support regular self checking (checking CPU, RAM, and I/O status every 10 seconds), and fault information is uploaded to the main controller or local alarm through communication (buzzer+flashing red LED).

Cross system compatibility: It can serve as an edge node for ABB AC 800M/Advant OCS system and upload data through Ethernet interface; Support communication with third-party PLCs (such as Siemens S7-1200) through Modbus protocol to receive control instructions from third-party systems; Adapt to third-party standard I/O modules (such as Schneider Modbus I/O modules) to reduce brand restrictions during system upgrades.

Low maintenance design: adopting fanless heat dissipation (natural heat dissipation through the shell) to reduce the risk of vulnerable parts (fan) failure; The selection of components focuses on long life (average life ≥ 5 years), and the wiring terminals adopt gold plating technology to reduce the problem of poor contact caused by oxidation and reduce the frequency of on-site maintenance.
