  • ABB TB807 module bus terminator
    ❤ Add to collection
  • ABB TB807 module bus terminator

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    The performance parameters of the TB807 module bus terminator directly determine its adaptability to the bus system and signal optimization effect. The core parameters are as follows:

    1. Bus adaptation type: mainly adapted to PROFIBUS DP bus, compatible with industrial fieldbus that complies with IEC 61158-2 standard, supports high-speed bus communication mode, adapts to bus transmission rate range of 9.6kbit/s~12Mbit/s, and can be flexibly matched according to bus system configuration.

    2. Impedance matching characteristics: Equipped with high-precision terminal resistors, the standard impedance value is 150 Ω (± 10%), which perfectly matches the characteristic impedance of PROFIBUS DP bus. It can effectively absorb the reflected signals at the end of the bus and avoid signal superposition interference.


    • ¥5867.00
      ¥6673.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:1.680KG
    • Quantity:
    • (Inventory: 99999)
Description

The performance parameters of the TB807 module bus terminator directly determine its adaptability to the bus system and signal optimization effect. The core parameters are as follows:

1. Bus adaptation type: mainly adapted to PROFIBUS DP bus, compatible with industrial fieldbus that complies with IEC 61158-2 standard, supports high-speed bus communication mode, adapts to bus transmission rate range of 9.6kbit/s~12Mbit/s, and can be flexibly matched according to bus system configuration.

2. Impedance matching characteristics: Equipped with high-precision terminal resistors, the standard impedance value is 150 Ω (± 10%), which perfectly matches the characteristic impedance of PROFIBUS DP bus. It can effectively absorb the reflected signals at the end of the bus and avoid signal superposition interference.





ABB TB807 module bus terminator

Core performance parameters

The performance parameters of the TB807 module bus terminator directly determine its adaptability to the bus system and signal optimization effect. The core parameters are as follows:

1. Bus adaptation type: mainly adapted to PROFIBUS DP bus, compatible with industrial fieldbus that complies with IEC 61158-2 standard, supports high-speed bus communication mode, adapts to bus transmission rate range of 9.6kbit/s~12Mbit/s, and can be flexibly matched according to bus system configuration.

2. Impedance matching characteristics: Equipped with high-precision terminal resistors, the standard impedance value is 150 Ω (± 10%), which perfectly matches the characteristic impedance of PROFIBUS DP bus. It can effectively absorb the reflected signals at the end of the bus and avoid signal superposition interference.

3. Signal processing capability: Equipped with signal shaping and amplification functions, it can enhance attenuated bus signals, improve the anti-interference ability of signal transmission, and extend the bus communication distance to 100m in high-speed transmission mode (12Mbit/s) and 1200m in low-speed mode (9.6kbit/s).

4. Power supply parameters: No independent external power supply is required, and the working power is directly obtained from the PROFIBUS DP bus through the bus interface. The working voltage range is DC 5V~30V, and the power consumption is extremely low (static power consumption ≤ 0.5W), which will not cause additional load on the bus power supply system.

5. Environmental adaptability: The working temperature range is -25 ℃~60 ℃, the storage temperature range is -40 ℃~85 ℃, and the relative humidity is 5%~95% (without condensation). It can adapt to complex industrial site environments such as high temperature, low temperature, and humidity.

6. Protection and physical characteristics: Adopting a compact plastic shell with a protection level of IP20, suitable for installation inside control cabinets; The module is compact in size (approximately 60mm x 35mm x 10mm in length, width, and height) and weighs only about 50g, saving installation space.


Functional Features

1. Efficient signal optimization to ensure stable communication

In industrial bus networks, signals are prone to reflection due to impedance mismatch when transmitted to the end of the bus. The superposition of the reflected signal and the original signal can cause signal distortion, leading to communication errors or interruptions. Through precise impedance matching design, TB807 can effectively absorb end reflection signals. At the same time, its built-in signal shaping circuit can filter high-frequency interference noise in bus transmission, repair distorted signal waveforms, significantly improve the stability of bus communication, reduce data transmission error rates, and increase the communication reliability of the bus system to over 99.9%.

2. Plug and play, easy to install

The module adopts a standard PROFIBUS DP bus connector interface (DB9 pin type), which supports direct plug-in installation at the end of the bus without complex wiring operations. The front of the module is equipped with status indicator lights (power indicator light and communication indicator light), which can intuitively display the working status of the module (the power indicator light is always on when the power is turned on, and the communication light flashes when the bus communication is normal), making it easy for on-site personnel to quickly judge the operation of the module.

3. High reliability and anti-interference design

Adopting industrial grade components and reinforced circuit design, it has excellent resistance to electromagnetic interference (EMI) and radio frequency interference (RFI), complies with EN 55022 and IEC 61000-4 series electromagnetic compatibility standards, and can work stably in strong electromagnetic environments on industrial sites. The module is equipped with an overvoltage protection circuit, which can quickly clamp the voltage when an instantaneous overvoltage occurs on the bus, protecting the module and bus equipment from damage.

4. Flexible adaptation and strong compatibility

TB807 is not only perfectly compatible with the PROFIBUS DP bus network of ABB AC 800M control system, but also compatible with third-party brands such as Siemens and Schneider's PROFIBUS DP bus devices, supporting mixed configuration of bus systems. Its wide transmission rate range supports bus systems that can meet different communication needs, whether it is high-speed real-time control production lines or long-distance transmission distributed monitoring systems, it can be stably adapted.

5. Maintenance free design reduces operation and maintenance costs

The module adopts a solid-state circuit design without mechanical wear and tear, with no vulnerable components, and a service life of over 100000 hours. At the same time, the module does not require independent power supply and complex parameter configuration, and can be automatically put into operation after installation. There is no need for dedicated maintenance during daily use, greatly reducing the operation and maintenance costs and workload of the bus system.


Applicable scenarios

The TB807 module bus terminator, as the "signal stabilizer" of the bus system, is widely used in various industrial automation scenarios using PROFIBUS DP bus. The core application scenarios include:

-Process Industry Bus System: In distributed control systems (DCS) for industries such as petrochemicals, chemical engineering, metallurgy, etc., it is used for signal optimization at the end of the PROFIBUS DP bus, ensuring stable communication between the controller and on-site I/O modules (such as AO845A eA) and actuators, and avoiding production stagnation caused by communication interruptions.

-Manufacturing production line bus: In the automation systems of production lines in industries such as automotive manufacturing and electronic assembly, PROFIBUS DP bus is adapted to ensure real-time data transmission between PLC and equipment such as robots, machine tools, sensors, etc., improving the operational stability of the production line.

-Energy and Power Monitoring Bus: In the monitoring system of power plants and substations, it is used to connect dispersed power monitoring equipment with the bus end of the central controller, ensuring stable transmission of key parameters such as voltage and current, and providing support for the safe operation of the power system.

-Long distance distributed bus network: In large industrial scenarios such as water treatment plants and mines, distributed devices are far away from the central controller, and bus signals are prone to attenuation. TB807 can extend bus communication distance through signal amplification and impedance matching, ensuring reliable communication of remote devices.

-Complex electromagnetic environment bus system: In strong electromagnetic interference scenarios such as steel plants and welding workshops, the anti-interference design of TB807 can effectively filter interference signals, ensure that bus communication is not affected by electromagnetic environment, and maintain normal system operation.


Key points for installation and use

1. Installation requirements

The module needs to be installed at the physical end of the PROFIBUS DP bus network and cannot be installed at intermediate nodes of the bus, otherwise it will cause impedance mismatch of the bus and affect communication quality. The installation location should be far away from high-temperature heat sources, strong electromagnetic radiation sources (such as frequency converters, high-power motors), and corrosive gases to avoid environmental impact on module performance. The module is installed inside the control cabinet and can be fixed to a 35mm standard DIN rail with snap fasteners, or directly fixed to the equipment terminals through bus connectors.

2. Usage and debugging steps

1. Confirm the transmission rate, bus length, and end position of the PROFIBUS DP bus network to ensure that TB807 is compatible with the current bus rate.

2. Connect the DB9 interface of the module directly to the PROFIBUS DP bus connector at the end of the bus, completing mechanical and electrical connections without the need for additional wiring.

3. Connect the power supply of the bus system and observe the module status indicator light: if the power light is constantly on, it indicates that the module is powered on normally; The communication light flashes according to the bus communication pattern, indicating that the module is working properly. If the indicator light does not light up or stays off, it is necessary to check whether the bus connection is secure.

4. Start the bus system and detect the bus communication status through the controller or bus diagnostic tool to confirm whether the communication error rate has decreased to a reasonable range (usually ≤ 0.1%). If there are still communication problems, check whether the bus wiring is standardized and whether there are other interference sources.
