    GE 859REF-A1-400 Motor Protection System

    • ¥23650.00
      ¥34670.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:3.400KG
    • Quantity:
    • (Inventory: 33)
Description

GE 859REF-A1-400 Motor Protection System


GE 859REF-A1-400 Motor Protection System

DESCRIPTION

The Multilin 859 Motor Protection System, a member of the Multilin 8 Series protective relay platform, is designed for the protection, control and management of medium and large power rating induction motors. It has also been purpose built as a direct replacement for GE’s existing range of Multilin motor protection relays including the 169, 269, 269Plus, and 369 devices.

Based on the same field proven hardware and protection and control algorithms of the Multilin 8 Series, the 859 delivers advanced features including high-speed protection, customizable programmable logic, and advanced motor monitoring and diagnostics - all in a fixed mount, slim design.

With extensive communication capabilities the 859 easily integrates into new or existing process control systems, enabling operationally focused motor management and control

Multilin 859 Overview

The Multilin 859 Motor Protection System is a protection device for managing, protecting and controlling medium to large horsepower motors.

With a fast protection pass, running every 1/8th of a cycle, the 859 relay provides fast current, voltage, power and frequency protection elements; reducing stress on the motor. The Multilin 859 supports the latest standard communications protocols, including IEC 62439/PRP and IEC 61850 Ed. 2 ; facilitating easy integration into new and existing SCADA/DCS networks.

Key Benefits

Utilizing GE's proven Thermal Model for reliable protection of AC induction motors

With a depth of 3.5", the 859 is ideal for MCCs with shallow depths or space constraints

Detachable display can be mounted up to 15 feet away from the device, allowing for greater installation flexibility

Large graphical color LCD display enhanced operability, with user-configurable single line diagrams for local control, system status and metering

Integrated condition monitoring based on Electrical Signature Analysis, delivering detailed monitoring & analytics for extended motor life

CyberSentry™ Advanced Security including features such as AAA, Radius, RBAC, and Syslog. helping to enable NERC® CIP compliance

Safe and reliable motor re-start on ‘down hole’ pump applications. Unique back spin detection feature detects flow reversal on a pump motor, enabling timely and safe motor restarting

Single setup & configuration software, reducing training & commissioning time

Customer Support available 24/7, available in multiple languages

High-Inertia Load Applications

The voltage-dependent overload curve feature in the Thermal Model protects motors that are used in high-inertia-load applications. Voltage is continually monitored when the motor is started and during acceleration. The thermal-limit curve is then adjusted accordingly. This enables the Multilin 859 to distinguish between a locked-rotor condition, an accelerating condition, and a running condition.

VFD-Driven Motor Applications

The Multilin 859 provides protection for motors fed through VFDs (Variable Frequency Drives). A wide range of the frequency tracking (3-72 Hz) allows the 859 to track the motor frequency and adjust its sampling rate to accurately measure phasors. An advanced algorithm allows switchable current and voltage tracking in case VFD is bypassed.

Thermal protection also considers the extra heating generated by the greater harmonics due to the VFD, to achieve an accurate response to the actual motor heating. RMS currents fed to the various motor-protection elements are further processed through the averaging filter to eliminate oscillations in current signals to ensure security.

Additionally, users can indicate a starting VFD frequency that helps the device track the motor frequency faster. Therefore, the 859 accurately measures the phasor quantities, which, otherwise, could cause delayed or false protection operation.

Cyclic Load Motor Applications

Input currents of a motor driving cyclic load can vary between very small to greater than the maximum allowable current during a load cycle. Variation in current magnitude results in motor heating and cooling depending on the heat and cooling time constants. Thermal overload protection response is adaptive to the cyclic load based on the cooling time constants. In addition, to provide more accurate overload thermal model response to cyclic load, the input currents to the thermal model are averaged over the settable duty-cycle interval. With a reciprocating-load application, the number of cycles to average can be determined from current waveform capture using the Oscillography/Datalogger features in the GE motor-protection relays.

Innovative  Technology & Design

• Proven algorithms delivering sub-cycle and  reliable differential protection

• Continuous monitoring and event driven  diagnostics for a wide range of generator  applications

• Patented environmental monitoring &  diagnostics

• Advanced, flexible and embedded  communications: IEC® 61850 Ed2, OPC-UA, IEC 62439/PRP, Modbus® RTU & TCP/IP,  DNP3.0, IEC 60870-5-104

• Single setup and configuration across the  8 Series platform

• Field swappable power supply

• Enhanced relay draw-out construction

• Elimination of electrolytic capacitors
