ABB LWN2660-6EG 3BHL000986P7002 Industrial Control Module

ABB LWN2660-6EG 3BHL000986P7002 Industrial Control Module

Product Overview

The ABB LWN2660-6EG 3BHL000986P7002 industrial control module is the core I/O processing unit in the ABB Advant OCS control system system, designed specifically for the acquisition, processing, and execution of control instructions for various types of signals in industrial sites. This module integrates high-density signal interfaces, high-speed data processing circuits, and redundant fault-tolerant mechanisms, which can achieve precise acquisition and real-time control of multiple types of signals such as analog, digital, and pulse signals. It seamlessly links with the controller through ABB's dedicated communication bus to build a stable and reliable distributed control network. It is widely used in process industries such as chemical, metallurgical, power, and papermaking, and is a key hardware carrier for achieving automated monitoring and precise control of production processes.

Core Basic Parameters

Product Model

LWN2660-6EG、3BHL000986P7002

manufacturer

ABB Group

Core processor

16 bit industrial grade microprocessor, with a main frequency of ≥ 80MHz, supporting hardware level data processing

Signal processing type

Analog input/output, digital input/output, pulse count (compatible with multiple types)

Analog input channel

8 channels, supporting 4-20mA/0-10V/± 5V, with complete isolation between channels

Analog output channel

4-channel, supports 4-20mA/0-10V, load capacity ≤ 500 Ω

Digital input channel

16 channels, DC 24V， Optoelectronic isolation, response time ≤ 1ms

Digital output channel

8 channels, relay output (AC 250V/5A, DC 30V/5A)

Pulse count channel

2 channels, supporting 0-10kHz pulse input, counting range 0-65535

Analog accuracy

Input accuracy ≤± 0.1% FS, output accuracy ≤± 0.2% FS

communication interface

ABB MasterBus 300 bus, supports hot swapping and redundant communication

power supply voltage

DC 24V ± 10%, with reverse connection protection function

Working temperature range

-10 ℃~60 ℃, humidity 10% -90% (no condensation)

Protection level

IP20 (standard rack installation)

Installation method

ABB standard DIN 41494 rack installation, supports hot swapping

Core functional characteristics

1. Integrated processing of multiple types of signals

The module adopts a multi-channel integrated design, integrating analog, digital, and pulse processing functions into a single unit. It can simultaneously access sensor signals such as temperature, pressure, and flow, as well as valve and pump actuator control signals, reducing the number of system hardware configurations. The analog channel adopts a 16 bit high-precision AD/DA conversion chip, combined with signal filtering and temperature compensation technology, with an input accuracy of ± 0.1% FS, effectively suppressing industrial field signal interference; The digital channel has photoelectric isolation and surge protection, and can be directly connected to industrial grade sensors and actuators without the need for additional adaptive components.

2. High speed data transmission and real-time response

Based on the ABB MasterBus 300 dedicated communication bus, the data transmission rate between the module and the controller can reach 1Mbps, and the signal acquisition cycle can be as low as 10ms, ensuring fast issuance of control instructions and real-time feedback of on-site data. The response time of the digital input channel is ≤ 1ms, which can accurately capture high-speed switch signals; The pulse counting channel supports pulse signal acquisition below 10kHz, suitable for flow measurement, speed monitoring and other scenarios, meeting the strict requirements of real-time control in the process industry.

3. Redundant fault-tolerant and high reliability design

The module supports bus redundancy and power redundancy configuration. When the main communication link or power supply fails, it can automatically switch to the backup circuit with a switching time of ≤ 50ms to ensure uninterrupted system control. Complete electrical isolation (isolation voltage ≥ 500Vrms) is adopted between channels to avoid measurement errors caused by signal crosstalk; The core components have undergone high and low temperature cycling, vibration and shock screening, and meet the IEC 61010 industrial equipment safety standard. The mean time between failures (MTBF) exceeds 80000 hours, making them suitable for continuous production in industrial environments.

4. Hot plugging and convenient maintenance

Adopting ABB standard hot swappable design, modules can be plugged and unplugged while the system is powered on, without interrupting the entire control system, greatly reducing equipment maintenance time. The module panel is equipped with channel status indicator lights (power, communication, channel faults), which can intuitively determine the operating status of each channel; Channel fault self diagnosis can be achieved through controllers or debugging software, accurately locating faulty channels and generating fault codes, making it easy for operation and maintenance personnel to quickly troubleshoot problems.

5. Flexible system integration and configuration

Compatible with ABB Advant OCS series controllers, it can seamlessly integrate with distributed control systems (DCS) and support linkage with monitoring software such as ABB Process Portal. The ABB Control Builder programming software allows for flexible configuration of channel parameters, such as signal type, range, and alarm threshold, without the need to modify hardware wiring to adapt to different types of sensors and actuators. The module supports signal calibration function, and analog channel zero and gain calibration can be completed through software, simplifying the debugging process.

6. Industrial grade safety assurance

Equipped with comprehensive safety protection functions, including power reverse connection protection, overvoltage protection (automatic clamping when input signal overvoltage occurs), and overcurrent protection (automatic disconnection when output channel overload occurs). The digital output adopts relay isolation output to avoid damage to the module caused by actuator failure; The module complies with CE and UL industrial certification standards, and its electromagnetic compatibility performance meets the requirements of IEC 61000-6-2 (anti-interference) and IEC 61000-6-4 (emission). It can operate stably in strong electromagnetic interference environments.

Applicable scenarios

-Chemical industry: Collection and control of temperature, pressure, and liquid level signals in chemical reaction vessels, combined with actuators to achieve precise control of reaction process parameters

-Metallurgical industry: Temperature monitoring of blast furnace hot blast stove in steel plants, pressure control of hydraulic system in rolling mills to ensure stable smelting and rolling processes

-Power industry: Collecting boiler feedwater flow and steam pressure signals for thermal power plants, participating in the closed-loop control of the unit coordinated control system (CCS)

-Paper industry: monitoring and control of tension in the paper machine mesh and drying cylinder temperature to ensure stable paper production quality and output

-Water treatment industry: Collection of dissolved oxygen concentration and pH value signals in the aeration tank of sewage treatment plants, control of aeration equipment and dosing pump operation

-Food and beverage industry: monitoring of sterilization temperature and material flow rate on production lines to achieve automated control and quality traceability of food processing processes
