  • ABB PCS6000 VLM70 3BHE034262R0001 Medium-Voltage Converter Module
    ❤ Add to collection
  • ABB PCS6000 VLM70 3BHE034262R0001 Medium-Voltage Converter Module

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    ABB PCS6000 VLM70 3BHE034262R0001 is a high-performance medium voltage frequency converter core power module launched by ABB, belonging to the PCS6000 series medium voltage frequency converter system. This module is designed specifically for medium voltage industrial application scenarios, with characteristics such as high reliability, high efficiency and energy saving, and strong environmental adaptability. As the power conversion core unit of the frequency converter, it undertakes the key functions of rectifying and inverting three-phase AC power, achieving precise voltage and frequency control, and providing stable and controllable power output for various medium voltage motors. It is widely used in heavy industry fields such as power, metallurgy, chemical industry, and building materials.

    • ¥16252.00
      ¥17636.00
      ¥16252.00
      ¥16252.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:0.634KG
    • Quantity:
    • (Inventory: 99999)
Description

ABB PCS6000 VLM70 3BHE034262R0001 is a high-performance medium voltage frequency converter core power module launched by ABB, belonging to the PCS6000 series medium voltage frequency converter system. This module is designed specifically for medium voltage industrial application scenarios, with characteristics such as high reliability, high efficiency and energy saving, and strong environmental adaptability. As the power conversion core unit of the frequency converter, it undertakes the key functions of rectifying and inverting three-phase AC power, achieving precise voltage and frequency control, and providing stable and controllable power output for various medium voltage motors. It is widely used in heavy industry fields such as power, metallurgy, chemical industry, and building materials.




ABB PCS6000 VLM70 3BHE034262R0001 Medium-Voltage Converter Module

Module Overview

ABB PCS6000 VLM70 3BHE034262R0001 is a high-performance medium voltage frequency converter core power module launched by ABB, belonging to the PCS6000 series medium voltage frequency converter system. This module is designed specifically for medium voltage industrial application scenarios, with characteristics such as high reliability, high efficiency and energy saving, and strong environmental adaptability. As the power conversion core unit of the frequency converter, it undertakes the key functions of rectifying and inverting three-phase AC power, achieving precise voltage and frequency control, and providing stable and controllable power output for various medium voltage motors. It is widely used in heavy industry fields such as power, metallurgy, chemical industry, and building materials.

Its design follows ABB's strict industrial standards and integrates advanced power electronics technology and intelligent control concepts. It can operate stably in complex working environments for a long time, effectively improving motor control accuracy in industrial production processes, reducing energy consumption, and lowering equipment maintenance costs. It is an indispensable core component of medium voltage variable frequency systems.


Core technical parameters

voltage level

Medium voltage level (usually suitable for 6kV/10kV systems)

Adapt to commonly used industrial medium voltage motor voltage standards, and can be matched and adjusted according to system requirements

power range

Compatible with PCS6000 series corresponding power range frequency converter (typical range 1000kW-5000kW)

Single module has high power density and can expand system power through parallel connection of multiple modules

topological structure

IGBT series multilevel topology (VLM technology)

Designed with a voltage source inverter, the output voltage waveform is close to a sine wave, reducing harmonic interference to the motor

Switching devices

High voltage IGBT (Insulated Gate Bipolar Transistor)

Featuring high-frequency switching characteristics, low switching losses, and strong voltage and current resistance capabilities

Output frequency range

0-60Hz (expandable to higher frequencies)

Meet the speed regulation requirements of motors under different working conditions and achieve precise speed control

efficiency

≥98.5%

Efficient power conversion capability, reducing energy loss, and meeting energy-saving requirements

cooling method

Forced air cooling/water cooling (depending on the application scenario)

Ensure temperature stability of the module during high load operation and extend device lifespan

Protection level

IP20 (module itself), system level protection can be upgraded to IP54 or above

Adapt to complex environments such as dust and water vapor in industrial sites to ensure the safe operation of modules


Structure and core characteristics

3.1 Modular Structure Design

This module adopts a highly integrated modular structure, encapsulating core components such as IGBT power devices, drive circuits, buffer circuits, and detection circuits into an independent unit. This design not only simplifies the installation and debugging process of the frequency converter system, but also facilitates later maintenance and troubleshooting - when a module fails, the system can be quickly restored by replacing the module as a whole, greatly reducing downtime. Meanwhile, standardized module interfaces make parallel expansion of multiple modules more convenient, meeting the application requirements of different power levels.

3.2 Core technological advantages

-VLM multilevel technology: Adopting a voltage source type multilevel topology, the medium voltage output is achieved through IGBT series connection. The output voltage waveform is composed of multiple level steps, close to a perfect sine wave, with extremely low harmonic content (THD ≤ 5%), which can effectively reduce damage to motor insulation, reduce motor operating noise, and extend motor service life without the need for additional harmonic filters.

-Efficient IGBT driving technology: Equipped with ABB's dedicated IGBT driving chip, it has complete overcurrent, overvoltage, and overheating protection functions, which can accurately control the switching process of IGBT, reduce switching losses, improve module efficiency, and quickly cut off the driving signal in case of faults, protecting power devices from damage.

-Intelligent state monitoring: The module is equipped with temperature sensors, voltage sensors, current sensors and other detection components, which can collect real-time operation status data of the module (such as IGBT temperature, output current, DC bus voltage, etc.), and upload the data to the main controller of the frequency converter to achieve real-time monitoring and fault warning of the module operation status.

-Strong environmental adaptability: Adopting a wide temperature design, it can operate stably within the temperature range of -10 ℃ to 45 ℃; The module is equipped with an efficient heat dissipation structure, combined with a reasonable air duct design, to ensure rapid heat dissipation and maintain temperature stability even under high load conditions.


Typical application scenarios

Based on its high reliability, stability, and energy efficiency, ABB PCS6000 VLM70 3BHE034262R0001 module is widely used in various industrial scenarios driven by medium voltage motors, mainly including:

1. Power industry: used for variable frequency speed regulation of auxiliary equipment such as induced draft fans, supply fans, primary fans, and feed pumps in thermal power plants, achieving precise flow control of fans and pumps, reducing power consumption, and improving unit operating efficiency; It is also applicable to the speed control system of hydroelectric power plants' hydro generator units.

2. Metallurgical industry: Suitable for equipment such as blast furnace fans, converter dust removal fans, rolling mill main drives, and continuous casting machine drives in steel plants, providing stable power output for metallurgical equipment, improving production process control accuracy, reducing equipment impact, and extending equipment service life.

3. Chemical industry: Used for variable frequency control of compressors and pump equipment (such as feed pumps and circulation pumps) in chemical plants, to meet the precise adjustment needs of flow and pressure in chemical production processes, ensure stable production processes, and reduce energy consumption and equipment maintenance costs.

4. Building materials industry: Suitable for rotary kiln main drive, cement mill, fan and other equipment in cement plants, as well as melting furnace fan, edge puller and other equipment in glass plants, to achieve smooth speed regulation of equipment, improve the stability and product quality of building materials production.

5. Municipal engineering: Used for variable frequency control of sewage lifting pumps, aeration fans, water supply pumps, and other equipment in large-scale sewage treatment plants, to achieve on-demand water supply and aeration, reduce municipal energy consumption, and improve sewage treatment efficiency.

Key points for installation and maintenance

5.1 Installation precautions

-The module installation must strictly follow the installation specifications of ABB PCS6000 series frequency converters, ensuring a clean and dry installation environment, away from interference sources such as dust, corrosive gases, and strong magnetic fields.

-The installation bracket of the module should have sufficient load-bearing capacity, avoid severe collisions during installation, and prevent damage to internal components of the module; Adequate heat dissipation space should be reserved between modules to ensure smooth air ducts.

-When wiring, it is necessary to strictly distinguish between the main circuit wiring and the control circuit wiring. The specifications of the main circuit cable should meet the current carrying requirements, and the wiring terminals should be securely fastened to prevent poor contact from causing heating; The control circuit wiring needs to be shielded to avoid electromagnetic interference.

-After installation, the insulation performance of the module needs to be tested. Use a megohmmeter to measure the insulation resistance of the main circuit to ensure that the insulation performance meets the requirements before conducting power on debugging.

5.2 Key points of daily maintenance

-Regular cleaning: According to the on-site environmental conditions, regularly (recommended once a month) clean the surface of the module and the heat dissipation air duct, remove dust and debris, and ensure the heat dissipation effect; For air-cooled modules, it is necessary to focus on cleaning the cooling fan and filter.

-Status monitoring: Real time monitoring of module operating parameters, including IGBT temperature, output current, voltage, etc., through the human-machine interface (HMI) of the frequency converter. If abnormal parameters are found (such as high temperature, large current fluctuations), the cause should be promptly investigated.

-Regular inspection: Conduct a comprehensive inspection of the module every six months to one year, including the tightness of the wiring terminals, the contact between the module and the heat sink, and the connection wires of the drive circuit. If any looseness, aging, or other problems are found, they should be dealt with in a timely manner.

-Fault handling: When a module malfunctions, it is necessary to first cut off the main power and control power of the frequency converter, and then perform maintenance after the module is completely discharged (usually taking more than 10 minutes); Troubleshooting requires the use of professional testing equipment, and it is strictly prohibited to disassemble modules while they are live.
