  • ABB RM302024 Relay
    ❤ Add to collection
  • ABB RM302024 Relay

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    Technical parameters are the core indicators for measuring relay performance. The parameter design of RM302024 relay accurately matches the actual needs of low-voltage distribution scenarios, as follows:

    -Basic electrical parameters: The rated voltage of the coil is 24V DC, which is suitable for common low-voltage DC power supply systems in industrial control and has strong compatibility; The rated current of the contact is 10A (under the load category of AC-15/DC-13), which can meet the control requirements of most small and medium power loads, and the contact switching ability is stable.


    • ¥12883.00
      ¥12556.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:1.260KG
    • Quantity:
    • (Inventory: 99999)
Description

Technical parameters are the core indicators for measuring relay performance. The parameter design of RM302024 relay accurately matches the actual needs of low-voltage distribution scenarios, as follows:

-Basic electrical parameters: The rated voltage of the coil is 24V DC, which is suitable for common low-voltage DC power supply systems in industrial control and has strong compatibility; The rated current of the contact is 10A (under the load category of AC-15/DC-13), which can meet the control requirements of most small and medium power loads, and the contact switching ability is stable.





ABB RM302024 Relay

Core technical parameters

Technical parameters are the core indicators for measuring relay performance. The parameter design of RM302024 relay accurately matches the actual needs of low-voltage distribution scenarios, as follows:

-Basic electrical parameters: The rated voltage of the coil is 24V DC, which is suitable for common low-voltage DC power supply systems in industrial control and has strong compatibility; The rated current of the contact is 10A (under the load category of AC-15/DC-13), which can meet the control requirements of most small and medium power loads, and the contact switching ability is stable.

-Action characteristics: Pull in voltage ≤ 85% of rated voltage, release voltage ≥ 10% of rated voltage, ensuring that the relay can reliably operate and reset within a range of small voltage fluctuations, avoiding misoperation caused by unstable voltage; The suction time is ≤ 15ms, the release time is ≤ 10ms, and the fast action response can timely respond to changes in the working conditions in the circuit.

-Environmental adaptation parameters: The working temperature range is -25 ℃~+70 ℃, which can adapt to various harsh environments such as severe cold and high temperature, and meet the temperature requirements of different regions and industrial scenes; The storage temperature range is -40 ℃~+85 ℃, which is convenient for product transportation and long-term storage; Relative humidity ≤ 95% (no condensation), it can still work stably in humid environments, improving the environmental tolerance of the product.

-Mechanical and lifespan parameters: Mechanical lifespan ≥ 10 million times, electrical lifespan (under AC-15 load) ≥ 100000 times, long-term service life reduces equipment maintenance frequency and replacement costs; The weight is about 50g and the volume is compact (specific dimensions are 45mm × 22mm × 58mm, subject to actual product), making it easy to install and layout in limited space scenarios such as distribution boxes.


Core functions and features

RM302024 relay relies on ABB's mature relay research and development technology, focusing on reliability, safety, and ease of use in functional design. The core features are as follows:

1. Reliable contact system: Made of silver alloy contact material, it has excellent conductivity and wear resistance, which can effectively reduce contact resistance, minimize arc damage to contacts, and improve the service life and switching stability of contacts; The contact adopts a bridge contact structure to ensure tight contact and reduce the risk of faults caused by poor contact.

2. Stable coil design: The coil is wound with high-strength enameled wire, with excellent insulation performance and a temperature resistance level of 155 ℃, which can effectively resist the heat generated by long-term operation and avoid coil burnout; The coil is equipped with freewheeling diodes (some models) at both ends, which can suppress the reverse electromotive force generated when the coil is powered off and protect other electronic components in the control circuit.

3. Multiple safety protections: The shell is made of engineering plastic with a flame retardant rating of UL94 V-0, which has good flame retardancy and insulation properties, and can effectively prevent fire risks caused by circuit short circuits; The product complies with international and national standards such as IEC 61810-1 and GB/T 14048.5, and has passed multiple rigorous safety certifications to ensure safety during use.

4. Convenient installation and wiring: Adopting standard DIN rail installation method, easy installation and disassembly, and can be quickly integrated into low-voltage distribution systems; The terminal block adopts a crimping design, with firm wiring, low contact resistance, and clear terminal identification for easy on-site construction and later maintenance.

5. Wide adaptability: Supports normally open/normally closed contact combinations (specific to product model), can be flexibly configured according to control requirements, and adapts to various scenarios such as start control, stop protection, signal interlocking, etc; It has strong compatibility with low-voltage electrical products such as contactors and circuit breakers under ABB, and can build a complete low-voltage distribution control solution.


Applicable scenarios

Based on its stable performance and flexible adaptability, RM302024 relay is widely used in low-voltage distribution systems in multiple fields, with typical application scenarios including:

-Industrial automation control: used for motor start-up control, overload protection signal transmission, and interlocking control between equipment in industrial equipment such as machine tools, production lines, fans, and water pumps, ensuring the continuous and stable industrial production process.

-Building electrical system: Used in the power distribution system of commercial buildings and residential communities, it is used for lighting circuit control, air conditioning system start stop control, and signal switching of fire emergency circuits to enhance the intelligence and safety of building electrical systems.

-In the field of rail transit: Low voltage auxiliary distribution systems suitable for subway, light rail and other rail transit, used to control traction system auxiliary equipment, station lighting, ventilation equipment, etc., to ensure the reliable operation of the rail transit system.

-In the field of new energy, it is used for signal detection and control circuit switching in low-voltage distribution circuits of photovoltaic inverters and energy storage systems to ensure the safe and stable output of new energy systems.

-Other low-voltage scenarios: It can also be applied to low-voltage control circuits in medical equipment, communication base stations, charging stations, and other scenarios, providing reliable signal conversion and control functions for various devices.


Installation and maintenance precautions

Proper installation and maintenance are key to ensuring the stable operation of RM302024 relay. Specific precautions are as follows:

1. Installation specifications

-Before installation, it is necessary to confirm that the product model is consistent with the actual requirements, check the appearance of the product for any damage, and ensure that the terminals are not deformed to ensure that the product is in good condition.

-The installation environment should meet the environmental parameter requirements of the product, avoiding installation in locations with direct sunlight, rainwater immersion, high dust concentration, or corrosive gases.

-When using DIN rail installation, it is necessary to ensure that the rail is firmly fixed and the relay is installed in place without looseness; When multiple relays are installed side by side, a minimum spacing of 5mm should be reserved for heat dissipation.

-When wiring, it is necessary to connect the power supply and load circuit according to the terminal identification, ensure that the wiring is firm, and avoid contact erosion caused by virtual connection; After the wiring is completed, the insulation performance needs to be checked to prevent short circuits.

2. Maintenance points

-Regularly inspect the appearance of the relay, check for any damage to the casing, burn marks on the contacts, and loose wiring, and promptly address any issues found.

-Regularly measure the coil resistance and insulation resistance. The coil resistance should meet the product parameter requirements, and the insulation resistance should be ≥ 10M Ω (measured by a 500V megohmmeter) to ensure good insulation performance.

-For relays that operate for a long time, it is recommended to conduct a comprehensive inspection every 3-5 years, including action characteristic testing, contact performance testing, etc., and replace products with decreased performance in a timely manner to avoid faults.

-During maintenance, it is necessary to cut off the power supply of relevant circuits to ensure safe operation; Avoid using corrosive cleaning agents to clean products, and use a dry soft cloth to wipe surface dust.
