ABB 3HNA001572-001 MCCB-02

F: | Au:FAN | DA:2025-04-27 | 872 Br: | 🔊 点击朗读正文 ❚❚ ▶ | Share:


Structure and design features

Mechanical structure

1. Plastic shell material: the shell is made of high-strength, flame-retardant engineering plastics, featuring light weight, excellent insulation performance and high mechanical strength. This material can not only effectively prevent electric shock accidents, but also resist a certain degree of external impact, to protect the internal electrical components from damage, and at the same time has good flame retardant properties, in the event of an electrical malfunction resulting in high temperatures, can prevent the spread of fire.

2. Modular design: Adopting the modular design concept, the internal disconnectors, operating mechanisms, terminals and other components can be replaced and maintained independently. This design makes the product more convenient in maintenance and upgrading, users can flexibly select and replace different functional modules according to the actual needs, such as replacing different protection characteristics of the off-trigger to adapt to different load requirements.

3. Compact shape: the overall structure is compact, small size, small space occupation, easy to install and layout in the distribution cabinet, distribution box and other electrical equipment with limited space. At the same time, its compact shape design is also conducive to improving the integration of the power distribution system and reducing the cost of equipment installation.

产品图片

Electrical design

1. Contact system: the contacts are made of high-quality silver alloy material with good electrical conductivity and arc resistance. During the opening and closing process, the contacts can quickly and reliably connect and disconnect the circuit, reduce arc generation, reduce contact wear, and improve the electrical life and reliability of the circuit breaker.

2. Arc extinguishing system: Equipped with high-efficiency arc extinguishing chamber, adopting special arc extinguishing grid structure and arc extinguishing materials. When the circuit breaks and generates an arc, the arc extinguishing chamber can quickly introduce the arc into the arc extinguishing grille, and then quickly extinguish the arc by splitting and cooling the arc, preventing the arc from damaging the contacts and other parts, ensuring that the circuit breaker can safely break the circuit under short-circuit and other fault conditions.


Application Fields

Industrial field

1. Factory power distribution system: in all kinds of industrial factories, it is used in workshop power distribution, lighting power distribution and other systems. Provide overload and short-circuit protection for motors, fans, pumps and other power equipments to ensure the normal operation of the equipments; at the same time, provide reliable electrical protection for the lighting lines to ensure the safe production and normal operation of the factory.

2. Automated production line: as the key protection equipment of the power distribution system of automated production line, it is used in conjunction with PLC, frequency converter and other automated equipments. In case of electrical faults in the production line, it can cut off the power supply in time, protect the expensive automation equipment from damage, and at the same time ensure the safe shutdown of the production line, and facilitate troubleshooting and maintenance.

3. New energy power station: In solar photovoltaic power station, wind power station and other new energy projects, it is used in the low-voltage power distribution system of the power station to protect the power generation equipment, energy storage equipment and related distribution lines, and to ensure the stable operation of the new energy power generation system.


Commercial and civil building field

1. Commercial buildings: widely used in shopping malls, office buildings, hotels and other commercial buildings in the power distribution system, for lighting, air conditioning, lifts, fire and other equipment to provide reliable electrical protection. It ensures safe and stable power supply in commercial buildings and meets the operation requirements of a large number of power-using equipments.

2. Residential area: It is used as the line protection equipment in the distribution box and distribution cabinet of residential area to protect the safety of household electricity consumption. When the family circuit overload, short circuit and other faults, timely cut off the power supply to prevent electrical fires and other accidents, to protect the lives and property of residents.

3. Public facilities: used in schools, hospitals, libraries and other public facilities of the power distribution system, for these places of lighting, electrical equipment, medical equipment, etc. to provide stable and reliable electrical protection, to ensure the normal operation of public facilities and personnel safety.
