HIMA F7105A Advanced PC Board Module for Industrial Control Solutions

HIMA F7105A Advanced PC Board Module for Industrial Control Solutions

The HIMA F7105A PC Board Module is designed for advanced industrial control systems, offering enhanced reliability and precision in automation processes. Type:PC Board Module Model:F7105A Manufacturer:HIMA Weight:0.3kg Dimensions:200mm x 100mm x 20mm Input Voltage Range:DC 12V to 24V Operating Temperature Range:-20掳C to +70掳C Communication Protocol:MODBUS RTU Number of Channels:16 Load Current per Channel:50mA Isolation Voltage:5000V AC Relay Rating:250VAC/10A, 250VDC/5A Operating Humidity Range:5% to 95% RH (non-condensing) The HIMA F7105A PC Board Module is a cutting-edge component designed for the most demanding industrial control applications. It boasts a compact yet robust design, engineered to withstand harsh environmental conditions, ensuring reliable operation in any industrial setting.

 Featuring advanced communication capabilities, the F7105A seamlessly integrates with existing systems via Modbus TCP/IP, facilitating efficient data exchange and remote monitoring. With its high-speed relay outputs and precise current consumption control, this module ensures swift response times and minimal power usage, making it ideal for applications requiring high performance and energy efficiency. Equipped with overcurrent protection, the F7105A safeguards against potential damage from electrical surges, enhancing system reliability and longevity. Compliant with international standards including CE and UL, the HIMA F7105A guarantees safety and compatibility across various global markets, providing peace of mind for manufacturers and end-users alike. Tag F7105A, F7105A catalog, F7105A PC Board Module, F7105A pdf, HIMA F7105A, HIMA HIMAX F

Instructions and warnings related to the operation of the product:

The following specifications must be strictly observed:

l The technical specifications and typical applications of the product system must be strictly observed.

l PERSONNEL TRAINING: Only trained personnel may install, operate, maintain or repair the product system. These personnel must be instructed on the

Hazardous area conditions must be instructed and explained to these personnel.

l Unauthorised modifications: No modifications or structural changes may be made to the product system.

l Maintenance Responsibility: It must be ensured that the product system is only used under appropriate conditions and in a condition that is fully fit for purpose.

l Working environment: The user must fulfil the specified environmental conditions:

Safety regulations

The following safety regulations must be fully observed when (maintenance) work is carried out on the product system:

1 Disconnect completely.

2 Secure to prevent reconnection.

3 Confirm that the installation has been completed.

4 Perform grounding and short-circuiting.
