GE DS3800NPPC Industrial Circuit Board, Optimized for Precision Control Applications

DS3800NPPC  Industrial Circuit Board, Optimized for Precision Control Applications

Model Number:DS3800NPPC Manufacturer:General Electric Module Type:Circuit Board Series:Mark IV DS3800 Board Type:Processor Interface Operating Voltage:24V DC Dimensions:120mm x 120mm x 30mm Weight:0.25kg Communication Interface:RS-485 Operating Temperature Range:-20"C to +60"C Storage Temperature Range:-40"C to +85"C Certifications:CE, UL, ISO 9001 The GE DS3800NPPC circuit board is a critical component in the Mark IV series of programmable logic controllers (PLCs), renowned for their robustness and efficiency in managing industrial automation processes. Engineered with precision, this circuit board features high-speed processing capabilities, enabling seamless integration with various industrial systems and devices.

 With its wide operating temperature range, the DS3800NPPC is designed to withstand harsh industrial conditions, ensuring continuous operation even under extreme environmental factors. Equipped with advanced communication protocols, this board facilitates efficient data exchange between different components, optimizing the overall performance of the automation system. Manufactured using premium materials, the DS3800NPPC offers unparalleled reliability and longevity, backed by industry-standard MTBF ratings, making it an ideal choice for long-term industrial applications. Easy to install and integrate, this circuit board simplifies the setup process for engineers, reducing downtime and streamlining the implementation of new automation solutions. The GE DS3800NPPC Circuit Board is a core component in industrial automation systems, designed for high-performance control and monitoring in manufacturing processes.

OTHER INFORMATION

• Up to 1.26 GHz Pentium® III processor with 256 KB advanced  transfer cache

• Up to 512 MB PC-133 SDRAM using a single SODIMM

• Internal AGP SVGA controller with 4 MB display cache

• 133 MHz system bus via Intel® 815E chipset

• Dual Ethernet controllers supporting 10BaseT and 100BaseTX  interfaces

• Optional PCI dual channel Ultra160 SCSI

• Up to three (two with rear I/O support) PMC expansion sites  (IEEE-P1386 common mezzanine card standard, 5 V)

• Up to 1 GB bootable flash on secondary IDE (optional)

• Two 16-bit and two 32-bit programmable timers

• 32 KB of nonvolatile SRAM

• Software-selectable watchdog timer with reset

• Remote Ethernet booting

• Optional IDE hard disk drive

• VME64 modes supported:  A32/A24/D32/D16/D08(EO)/MBLT64/BLT32

• VMEbus interrupt handler, interrupter and system controller

• Includes real time endian conversion hardware for littleendian and big-endian data interfacing (patent no. 6,032,212)

• Enhanced bus error handling

• Passive heat sink
