GE Fanuc IC697BEM731F Advanced Bus Controller Module, High Performance PLC Component

GE Fanuc IC697BEM731F  Advanced Bus Controller Module, High Performance PLC Component

Operating Voltage:5.0 Volts DC Dimensions:Specific dimensions for compact installation Weight:Approximately 0.4kg Connectors:One Bus Controller channel, One Hand-Held Terminal port Bus Cable Type:Belden 9182 series The GE Fanuc IC697BEM731F Bus Controller Module is a robust and versatile component designed to streamline your industrial automation processes.

This module ensures seamless communication and control within your manufacturing environment, enhancing productivity and efficiency.

Featuring a built-in bus controller channel and a hand-held terminal port, this module provides direct access to your system  components, enabling real-time monitoring and adjustment without the need for complex wiring.

With support for both 3PL and 1PL connectors, the IC697BEM731F offers flexibility in connectivity, allowing for easy integration with a wide range of industrial devices. Its compatibility with Belden 9182 type cables ensures reliable and efficient data transmission over longer distances.

Built for durability and performance, the GE Fanuc IC697BEM731F is engineered to withstand the harsh conditions typically found in industrial environments, ensuring longevity and reliability in your production line.

This module is part of the GE Fanuc PLC series, known for its advanced technology and user-friendly design. It supports a broad range of applications, from simple automation tasks to complex control systems, making it an ideal choice for businesses looking to optimize their operations.

The GE Fanuc IC697BEM731F Bus Controller Module is an advanced bus controller designed for seamless integration and control in industrial automation systems, ensuring reliable communication and data transfer.

Features

 Single-Slot Module

 SNP/SNP-X Protocol (master, slave)

 CCM Protocol (master, slave, peer)

 RTU Modbus Protocol (slave only)

 Supports connection to MS-DOS or Windows

 programming and configuration software package (monitor only)

 12 Mhz, 80C186 Microprocessor

 Two RS-422/RS-485 or RS-232 Serial Ports

 CCM, RTU and SNP/SNP-X Available on Either or Both Ports

 Simultaneous Communications on Both Ports (up to 9.6 Kbps, or 19.2 Kbps individually)

 High Performance Access to PLC Memory

 Three Status LEDs

 Reset pushbutton

 Soft Switch Configuration (no switches or jumpers)

 No Battery Required

Ease of Use

• Simple and powerful instruction set

• One-axis or two-axis motion programs with synchronized block start

• Program support for a short motion program (called Program Zero) which can be created in the MS-DOS programming software configuration function

• Nonvolatile (flash) storage for 10 programs and 40 subroutines

• User scaling of programming units (in Standard mode only)

• Generic programming using command parameters as operands for Acceleration, Velocity, Move and Dwell commands

• Configured with MS-DOS configuration software
