Product Overview

ABB 500TRM02 (order number 1MRB150011R0001) is a high-precision monitoring relay designed specifically for the safe and stable operation of power transformers, and is a core member of the ABB 500 series relay product system. This product integrates multi-dimensional parameter monitoring and intelligent protection functions, which can capture key status information during the operation of transformers in real time. Through precise judgment and rapid response, it effectively prevents equipment failures, extends service life, and provides solid guarantees for the reliable operation of the power system. It is widely used for oil immersed and dry-type transformer protection in industrial distribution systems, substations, new energy power stations and other scenarios.

Core functions and protective features

The monitoring relay is designed with the core concept of "comprehensive monitoring, precise protection, and convenient operation and maintenance", and has the following key functions:

2.1 Multi parameter real-time monitoring

-Temperature Monitoring: Supports dual monitoring of transformer winding temperature and top oil temperature, compatible with commonly used temperature sensors such as Pt100. The measurement range covers -50 ℃ to 200 ℃, with an accuracy of ± 0.5 ℃. It can track the device's heating status in real time to avoid overheating damage.

-Oil level and oil quality monitoring: By connecting oil level sensors and dissolved gas monitoring modules in the oil, real-time feedback on transformer oil level and oil quality deterioration is provided, and timely warnings of oil leakage, insulation performance degradation, and other issues are issued.

-Electrical parameter monitoring: Integrated with functions for collecting electrical quantities such as current, voltage, and power, it can monitor changes in transformer load, identify abnormal working conditions such as overload and unbalanced load, and provide data support for load adjustment.

2.2 Classification protection and response mechanism

The product adopts a three-level protection logic of "warning alarm trip", and users can customize the threshold values for each level according to the transformer operation regulations:

1. Warning stage: When the monitoring parameters approach the threshold, the relay emits an audible and visual warning signal to remind the operation and maintenance personnel to pay attention to the equipment status. At this time, it does not affect the normal operation of the transformer.

2. Alarm stage: When the parameters reach the threshold but do not endanger the safety of the equipment, an alarm output is triggered, and the fault information is uploaded to the monitoring system for easy problem localization.

3. Trip stage: When the parameters seriously exceed the standard (such as a sharp increase in winding temperature or a sudden drop in oil level), quickly output a trip signal to cut off the transformer power supply and avoid the fault from expanding.

2.3 Data recording and communication functions

Built in large capacity data storage module can record nearly a thousand fault information, parameter change curves, and operation logs, including fault type, occurrence time, parameter values, etc., providing a basis for fault tracing and equipment diagnosis. In terms of communication, it supports mainstream communication protocols such as RS485 and Modbus RTU, and can seamlessly integrate with control systems such as SCADA and DCS to achieve remote monitoring, parameter setting, and control operations, improving the level of operation and maintenance automation.

2.4 Self diagnosis and Reliability Design

Equipped with a comprehensive self diagnostic function, it can detect the working status of its own power supply, sensor access, output circuit and other components in real time. If it malfunctions, it will immediately issue a fault alarm to avoid protection loss caused by relay failure. The product adopts industrial grade components, with a shell protection level of IP54, and has characteristics such as anti electromagnetic interference, high and low temperature resistance (working environment temperature -25 ℃ to 70 ℃), and anti vibration, adapting to complex on-site operating environments.

Key technical parameters

power input

AC 220V/380V ±10%，50/60Hz；DC 24V/48V ±15%

Temperature measurement range

-50 ℃~200 ℃ (winding); -30 ℃~150 ℃ (oil temperature)

Current measurement range

0~1000A (connected through current transformer, variable ratio can be set)

output method

4 sets of relay outputs (NO/NC optional), capacity AC 250V/5A, DC 30V/5A

communication interface

RS485， Supports Modbus RTU protocol

Protection level

IP54 (panel), IP20 (terminal)

Installation method

DIN rail installation (35mm standard rail)

Overall dimensions

144mm x 108mm x 72mm (length x width x height)

Key points for installation and debugging

4.1 Installation Requirements

-The installation location should be away from strong magnetic fields, heat sources, and corrosive gases, ensuring good ventilation for easy observation and operation.

-Fixed with 35mm standard DIN rail, securely installed to avoid loose wiring or parameter drift caused by vibration.

-When wiring, it is necessary to strictly distinguish between the power circuit, sensor circuit, and output circuit to ensure correct polarity and avoid short circuits or misconnections.

4.2 Debugging steps

1. Power check: Connect the rated power supply and observe whether the power indicator light is lit up normally without any abnormal alarms.

2. Sensor calibration: Connect the standard signal source to simulate the sensor output, check whether the relay display value is consistent with the standard value, and if there is a deviation, calibrate it through buttons or software.

3. Parameter setting: Based on the transformer model and operating requirements, set warning values, alarm values, and trip values for parameters such as temperature, current, and oil level to ensure that the protection logic meets on-site requirements.

4. Functional testing: Simulate various fault conditions (such as temperature rise and overload), check whether the relay can issue warning, alarm, and trip signals according to the preset logic, and whether the communication function uploads data normally.

Maintenance and common troubleshooting

5.1 Daily Maintenance

-Regularly clean the surface and terminal block of the equipment, remove dust and oil stains, and avoid poor contact.

-Check the wiring terminals for looseness once a month, and ensure that the sensor connections are intact without damage or aging.

-Review parameter settings quarterly to ensure consistency with operating procedures, and regularly export and backup data records.

5.2 Common faults and solutions

Fault phenomenon

Possible reasons

treatment method

The power indicator light is not on

Power supply not connected, power line failure, or internal power module damage

Check the power wiring and voltage, replace the faulty circuit; If the power module is damaged, contact the manufacturer for repair

Abnormal temperature display (high/low)

Sensor malfunction, loose wiring, or calibration failure

Check the sensors and wiring, recalibrate; Replace the faulty sensor

No alarm/trip output

Parameter setting errors, output circuit faults, or damaged relay contacts

Review parameter settings and check output circuit wiring; Replace the faulty relay contacts

Communication interruption

Communication line failure, protocol mismatch, or communication address conflict

Check the communication line, reconfigure communication parameters (address, baud rate) to avoid address conflicts

Product advantages and application scenarios

6.1 Core advantages

-High integration: Integrating multi-dimensional monitoring and protection functions into one, reducing equipment footprint and wiring complexity, and lowering system construction costs.

-Reliable accuracy: High precision measurement chips and mature algorithms are used to ensure small parameter monitoring errors, accurate protection actions, and avoid misoperation or refusal to move.

-Easy to operate: equipped with clear LCD display screen and buttons, supporting local parameter settings; Simultaneously supporting remote communication for centralized operation and maintenance.

-Strong compatibility: Compatible with different types of sensors and control systems, adaptable to various specifications of transformers, and flexible in application.

6.2 Typical Application Scenarios

-Industrial enterprises: protection for main transformers in factory power distribution systems and step-down transformers in workshops.

-Power system: Monitoring of oil immersed power transformers in substations and distribution rooms.

-New energy field: Protection of step-up transformers in photovoltaic power plants and wind power projects.

-Public facilities: monitoring of backup transformers in important places such as hospitals, data centers, and commercial complexes.
