  • ABB DAPI100 3AST000929R109 Ethernet Communication Interface Module
    ❤ Add to collection
  • ABB DAPI100 3AST000929R109 Ethernet Communication Interface Module

    ABB DAPI100 (order number: 3AST000929R109) is a high-performance Ethernet communication interface module for industrial automation control systems, belonging to the core adapter series of ABB's industrial communication product family. Its core positioning is to serve as a "data bridge" between industrial equipment and Ethernet networks, enabling bidirectional data exchange between industrial equipment such as PLCs, controllers, I/O modules, intelligent instruments, and upper monitoring systems (SCADA/HMI), enterprise management systems (MES/ERP), and cloud platforms through standardized Ethernet protocols. It solves communication compatibility issues between different devices in industrial sites and is a key component in building transparent and efficient industrial communication networks.

    • ¥24774.00
      ¥28447.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:10.560KG
    • Quantity:
    • (Inventory: 99999)
Description

ABB DAPI100 (order number: 3AST000929R109) is a high-performance Ethernet communication interface module for industrial automation control systems, belonging to the core adapter series of ABB's industrial communication product family. Its core positioning is to serve as a "data bridge" between industrial equipment and Ethernet networks, enabling bidirectional data exchange between industrial equipment such as PLCs, controllers, I/O modules, intelligent instruments, and upper monitoring systems (SCADA/HMI), enterprise management systems (MES/ERP), and cloud platforms through standardized Ethernet protocols. It solves communication compatibility issues between different devices in industrial sites and is a key component in building transparent and efficient industrial communication networks.




ABB DAPI100 3AST000929R109 Ethernet Communication Interface Module

Product Overview

ABB DAPI100 (order number: 3AST000929R109) is a high-performance Ethernet communication interface module for industrial automation control systems, belonging to the core adapter series of ABB's industrial communication product family. Its core positioning is to serve as a "data bridge" between industrial equipment and Ethernet networks, enabling bidirectional data exchange between industrial equipment such as PLCs, controllers, I/O modules, intelligent instruments, and upper monitoring systems (SCADA/HMI), enterprise management systems (MES/ERP), and cloud platforms through standardized Ethernet protocols. It solves communication compatibility issues between different devices in industrial sites and is a key component in building transparent and efficient industrial communication networks.

This module integrates ABB's technological advantages in industrial communication protocol parsing and anti-interference design, with features such as high communication speed, strong protocol compatibility, good stability, and outstanding anti-interference ability. It can adapt to the complex electromagnetic environment and harsh operating conditions of industrial sites such as metallurgy, chemical, power, and automotive manufacturing. Its modular design supports quick installation and flexible configuration, and can be seamlessly integrated into mainstream control systems such as ABB AC 800M and Symphony Plus. It is also compatible with third-party industrial equipment, greatly reducing the difficulty of system communication integration.

Core functions and roles

2.1 Multi protocol data conversion and forwarding

The DAPI100 module has powerful protocol conversion capabilities and can achieve bidirectional conversion between industrial equipment specific protocols and standard Ethernet protocols. The module is equipped with various mainstream industrial communication protocol parsing engines, including PROFIBUS DP, Modbus RTU/TCP, EtherNet/IP, ABB dedicated PPA bus protocol, etc. It can convert the dedicated protocol data output by PLC or controller into TCP/IP Ethernet protocol data and upload it to the upper monitoring system; At the same time, convert the Ethernet control instructions issued by the upper system into a dedicated protocol that can be recognized by the device, achieving remote control of on-site equipment. For example, I/O data from the PROFIBUS DP bus can be converted to Modbus TCP protocol and connected to an Ethernet based SCADA system, breaking down barriers between different communication buses.

2.2 High speed Ethernet data transmission

The module supports 10/100Mbps adaptive Ethernet interface and adopts full duplex communication mode, with stable data transmission rate and low latency, meeting the needs of industrial real-time control. In the data upload scenario, real-time data collection and transmission at the millisecond level (≤ 5ms) can be achieved to ensure that the upper system can timely obtain the operating status of on-site equipment; In the scenario of issuing control instructions, the response time for instruction transmission is ≤ 2ms, ensuring the accuracy and timeliness of remote control. In addition, the module supports data frame priority setting, which can assign high priority to critical control data to avoid transmission delays caused by network congestion and ensure that the core control process is not affected.

2.3 Network redundancy and high availability guarantee

In response to the high reliability requirements of industrial communication, the DAPI100 module supports dual Ethernet port redundancy configuration (1+1 redundancy), where two Ethernet ports can be connected to different network switches to form a redundant communication link. When the main communication link fails (such as network cable breakage or switch failure), the module can automatically switch to the backup link within 10ms without interruption of data transmission, ensuring the continuity of the communication network. At the same time, the module has a network fault self diagnosis function, which can monitor the link status in real time. When a link abnormality is detected, it is immediately fed back to the upper system through an alarm signal, making it easy for operation and maintenance personnel to quickly troubleshoot the fault.

2.4 Industrial grade anti-interference and environmental adaptation

The module adopts industrial grade electromagnetic compatibility design and has strong anti-interference ability. Through the built-in electromagnetic shielding layer and signal filtering circuit, it can effectively resist electromagnetic radiation, pulse interference, and voltage fluctuations in industrial sites, complying with the IEC 61000-4 series electromagnetic compatibility standards; The module power interface has overvoltage, overcurrent, and reverse connection protection functions, which can work stably within the voltage fluctuation range of DC 24V ± 20%, avoiding module damage caused by power supply abnormalities. In addition, the module supports a wide temperature range of -25 ℃~+60 ℃, with a relative humidity tolerance of 5%~95% (without condensation), and can adapt to industrial site environments with high temperature, high humidity, and high dust.

2.5 Flexible Configuration and Remote Management

The module supports multiple configuration methods, including local configuration through RS-232 debugging interface, web page configuration through Ethernet network, and centralized configuration through ABB dedicated configuration software (such as ABB Communication Studio). Operators can set module IP addresses, subnet masks, gateways, communication protocol types, data mapping relationships, and redundant parameters through the configuration interface, making the configuration process simple and intuitive. At the same time, the module supports SNMP network management protocol, and the upper management system can remotely monitor the module's operating status (such as communication speed, link status, CPU load) through this protocol, and achieve remote firmware upgrades without the need for on-site module disassembly, reducing maintenance costs.


Key technical parameters

Order Number

3AST000929R109

Product Model

DAPI100

Product Type

Industrial Ethernet communication interface module (protocol conversion type)

Ethernet interface

2 RJ45 ports, 10/100Mbps adaptive, supporting full duplex/half duplex

Serial communication interface

1 RS-232 (debugging), 1 RS-485 (supporting PROFIBUS DP)

Supported Protocols

EtherNet/IP、Modbus RTU/TCP、PROFIBUS DP V1、ABB PPA、SNMP

Data transmission rate

Ethernet: 10/100Mbps; PROFIBUS DP: up to 12Mbps; Modbus RTU: up to 115.2kbps

communication delay

Data forwarding delay ≤ 5ms, control instruction response time ≤ 2ms

redundant function

Support dual Ethernet port redundancy, switching time ≤ 10ms

Working Voltage

DC 24V ± 20%, supports reverse connection protection

Working temperature range

-25℃ ~ +60℃

relative humidity

5%~95% (non condensing)

Protection level

IP20 (module body), requires coordination with the control cabinet to achieve higher protection

Electromagnetic compatibility standards

IEC 61000-4-2 (ESD), IEC 61000-4-3 (Radiated Immunity), IEC 61000-4-4 (Electrical Fast Transient)

Installation method

DIN 35mm standard rail installation

configuration method

Web page configuration, RS-232 debugging configuration, ABB Communication Studio software configuration


Structure composition and interface description

4.1 Core Structure Composition

The DAPI100 module adopts a compact modular structure, mainly composed of five core components: the first is the core processing unit, equipped with a high-performance 32-bit embedded processor, responsible for protocol parsing, data conversion and forwarding, and overall module control; The second is the Ethernet communication unit, which includes two Ethernet physical layer chips and RJ45 interfaces to achieve the transmission and reception of Ethernet data; The third is a serial communication unit that integrates RS-232 and RS-485 interface circuits for debugging, configuring, and connecting PROFIBUS DP devices; The fourth is the power management unit, which includes power filtering and overvoltage/overcurrent protection circuits to provide stable power supply for each unit of the module; The fifth is the status indicator unit, which consists of multiple LED indicator lights and provides real-time feedback on the power supply, communication link, and module operation status.

4.2 Key Interface and Indicator Light Description

-Ethernet interface (ETH1/ETH2): located on the right side of the front of the module, with two RJ45 interfaces labeled "ETH1" (main link) and "ETH2" (backup link) respectively, used to connect Ethernet switches or upper level devices; Each interface is equipped with two LED indicator lights, with a green light indicating link connectivity (constantly on) and a yellow light indicating data transmission (flashing).

-Serial interface: includes one DB9-pin RS-232 interface (labeled "CONFIG" for local debugging configuration) and one Phoenix terminal RS-485 interface (labeled "PROFIBUS DP" for connecting PROFIBUS DP slave devices). The RS-485 interface supports differential signal transmission and has strong anti-interference ability.

-Power interface: located on the left side of the rear of the module, in the form of a phoenix terminal, labeled with "V+" and "V -", supporting DC 24V input, equipped with a power status indicator light (green constant light indicates normal power supply, red light indicates power failure).

-Status indicator lights: There are 4 sets of LED indicator lights at the front of the module, namely power light (PWR), running light (RUN, green flashing indicates normal operation), fault light (ERR, red on indicates module failure), and redundancy status light (RED, yellow on indicates main link working, green on indicates backup link working).

-Reset button: located on the left side of the front of the module, labeled "RESET", used for module reset or factory reset (long press for 5 seconds), convenient for fault handling and parameter reset.
