  • ABB O3EHa HENF315087R2 Digital Output Module
    ❤ Add to collection
  • ABB O3EHa HENF315087R2 Digital Output Module

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    ABB O3EHa (order number: HENF315087R2) is a high stability digital output (DO) module designed for industrial automation core control scenarios. It belongs to the ABB Advant OCS and AC 800M control system supporting I/O product series. The core function of this module is to serve as an "instruction converter" between the control system and external actuators, reliably converting the weak electrical logic signals output by the controller into strong electrical signals that can drive industrial equipment such as valves, contactors, and indicator lights, achieving precise start stop and state switching control of various types of actuators in the production process.

    • ¥7547.00
      ¥8547.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:3.566KG
    • Quantity:
    • (Inventory: 99999)
Description

ABB O3EHa (order number: HENF315087R2) is a high stability digital output (DO) module designed for industrial automation core control scenarios. It belongs to the ABB Advant OCS and AC 800M control system supporting I/O product series. The core function of this module is to serve as an "instruction converter" between the control system and external actuators, reliably converting the weak electrical logic signals output by the controller into strong electrical signals that can drive industrial equipment such as valves, contactors, and indicator lights, achieving precise start stop and state switching control of various types of actuators in the production process.


ABB O3EHa HENF315087R2 Digital Output Module

Product Overview

ABB O3EHa (order number: HENF315087R2) is a high stability digital output (DO) module designed for industrial automation core control scenarios. It belongs to the ABB Advant OCS and AC 800M control system supporting I/O product series. The core function of this module is to serve as an "instruction converter" between the control system and external actuators, reliably converting the weak electrical logic signals output by the controller into strong electrical signals that can drive industrial equipment such as valves, contactors, and indicator lights, achieving precise start stop and state switching control of various types of actuators in the production process.

With ABB's mature technology accumulation in the field of industrial control, the O3EHa module has strong anti-interference ability, wide load adaptation range, stable and reliable operation, and can adapt to harsh industrial environments with high dust, high electromagnetic interference, and large temperature fluctuations in industries such as power, metallurgy, chemical, and intelligent manufacturing, providing solid signal output guarantee for the continuous operation of automation systems.

Core technical parameters

2.1 Basic specification parameters

-Module model: O3EHa

-Official order number: HENF315087R2

-Module type: DC digital output module

-Adaptive control system: ABB Advant OCS, AC 800M series DCS/PLC system

-Power supply requirement: DC 24V ± 10% (typical operating voltage), with overvoltage protection (protection threshold ≥ 30V DC)

-Module power consumption: Static power consumption ≤ 1.8W, full load operation power consumption ≤ 8W (varies with output channel load)

-Bus communication: Supports ABB standard I/O bus protocol and enables high-speed data exchange with the controller

2.2 Core parameters of output channel

-Number of channels: 16 channels (independent output, supporting single channel independent control)

-Output type: transistor output (NPN/PNP optional, default NPN type)

-Output voltage range: DC 10V-30V (suitable for mainstream industrial DC loads)

-Single channel output capability: maximum continuous output current 0.5A (resistive load), peak output current 1A (duration ≤ 100ms)

-Output response speed: ≤ 5ms (from control signal triggering to stable output state)

-Channel isolation characteristics: Optical and electrical isolation between channels and between channels and backplane bus, isolation voltage ≥ 2500Vrms (1-minute withstand voltage test)

-Load type adaptation: Supports resistive, inductive, and capacitive loads, with inductive loads requiring external current diodes

2.3 Environmental and Mechanical Characteristics

-Working temperature range: -25 ℃~+65 ℃ (wide temperature design, suitable for extreme industrial environments)

-Storage temperature range: -40 ℃~+85 ℃ (meets transportation and storage needs in harsh environments)

-Relative humidity: 5%~95% (no condensation, in accordance with IEC 60068-2-3 standard)

-Anti interference performance: Complies with IEC 61000-4 series standards, with electrostatic discharge immunity of ± 8kV (contact)/± 15kV (air), and electrical fast transient pulse group immunity of ± 2kV

-Protection level: IP20 (module body), can provide protection of IP54 or above when installed in a standard control cabinet

-Installation method: 35mm standard DIN rail installation, supporting dense module layout and cascading expansion

-Dimensions: Approximately 35mm in width, 110mm in height, and 130mm in depth (subject to actual product)


Core functions and technological advantages

3.1 High reliability and safety protection

The module adopts industrial grade reinforced design, and each output channel is equipped with independent overcurrent protection and short-circuit protection circuits. When the load short circuit or current exceeds the rated value, the output circuit can be quickly cut off to avoid module damage and fault propagation. At the same time, the module is equipped with a surge suppression circuit, which can effectively absorb the transient overvoltage generated during the load switching process, protecting internal components and backend load equipment. In addition, the wide temperature working range and high-level isolation design enable it to operate stably in high temperature and high interference industrial scenarios, reducing the risk of failures caused by environmental factors.

3.2 Multi scenario load adaptation capability

In response to the diverse load types in industrial sites, the O3EHa module can stably drive various loads such as DC solenoid valves, small servo motors, LED indicator lights, DC contactors, etc. through optimized transistor output circuit design. Its continuous output current of 0.5A and peak output current of 1A can meet the driving needs of most small and medium power DC loads; At the same time, the module supports a wide load voltage range of DC 10V-30V, without the need for additional voltage conversion equipment, and can directly adapt to different specifications of DC load circuits, improving system integration flexibility.

3.3 Accurate state monitoring and diagnosis

The module is equipped with complete status indication and fault diagnosis functions. The front is equipped with a power indicator light (PWR), a module running indicator light (RUN), and 16 independent channel output indicator lights (CH1-CH16). Operation and maintenance personnel can intuitively judge the module power supply status, bus communication status, and whether each channel output is normal through the indicator lights. In addition, the module supports feedback of channel overcurrent, short circuit and other fault information to the controller through the bus, which, in conjunction with the upper system, can achieve remote alarm and location of faults, greatly reducing operation and maintenance troubleshooting time.

3.4 Convenient Integration and Expansion

By adopting ABB's standardized module interface and bus protocol, it can directly connect to control systems such as Advant OCS and AC 800M without the need for complex protocol configuration and hardware modification, achieving a "plug and play" integration. The module adopts a compact structural design, and the DIN rail installation method supports dense arrangement of multiple modules, saving internal space of the control cabinet; At the same time, the module supports cascading expansion of I/O modules in the same series as ABB, and can flexibly increase or decrease the number of output channels according to control requirements, adapting to different scenarios from small equipment control to large production line control.
