  • ABB SPAJ140C overcurrent and ground fault relay
    ❤ Add to collection
  • ABB SPAJ140C overcurrent and ground fault relay

    110V-380V
    5W-130W
    1A-30A
    1 year
    30
    United States, France, Japan, Viet Nam, Australia, Russia, Germany, Italy, Arabia

    The SPAJ140C relay is developed based on ABB's advanced power protection hardware platform, and its core features are concentrated in four advantages: "precise protection, fast response, flexible adaptation, and stable reliability". In terms of protection accuracy, a 32-bit high-performance microprocessor and a 16 bit high-precision A/D conversion module are used, with a current measurement accuracy of ± 0.5% and minimal fault diagnosis error, ensuring the accuracy of protection actions. In terms of response speed, for serious faults such as short circuits, the protection action time can be as low as 10ms, which can quickly cut off the circuit in the early stages of the fault, minimizing equipment damage and power outage range. In terms of adaptability, it supports multiple current transformer (CT) ratio configurations and is compatible with distribution lines of different capacities; It has rich communication interfaces and protection logic configuration functions, and can customize protection parameters according to different distribution scenarios. In terms of reliability, it adopts industrial grade wide temperature element devices and reinforced housing design, certified by the IEC 60255 series power relay standard, with an average time between failures (MTBF) of over 200000 hours, and can operate stably in wide temperature environments ranging from -25 ℃ to 70 ℃, as well as high humidity and dusty industrial scenarios.

    • ¥27366.00
      ¥28477.00
    • Satisfaction:

      Sales: 0

      Review: 0

    Weight:12.000KG
    • Quantity:
    • (Inventory: 99999)
Description

The SPAJ140C relay is developed based on ABB's advanced power protection hardware platform, and its core features are concentrated in four advantages: "precise protection, fast response, flexible adaptation, and stable reliability". In terms of protection accuracy, a 32-bit high-performance microprocessor and a 16 bit high-precision A/D conversion module are used, with a current measurement accuracy of ± 0.5% and minimal fault diagnosis error, ensuring the accuracy of protection actions. In terms of response speed, for serious faults such as short circuits, the protection action time can be as low as 10ms, which can quickly cut off the circuit in the early stages of the fault, minimizing equipment damage and power outage range. In terms of adaptability, it supports multiple current transformer (CT) ratio configurations and is compatible with distribution lines of different capacities; It has rich communication interfaces and protection logic configuration functions, and can customize protection parameters according to different distribution scenarios. In terms of reliability, it adopts industrial grade wide temperature element devices and reinforced housing design, certified by the IEC 60255 series power relay standard, with an average time between failures (MTBF) of over 200000 hours, and can operate stably in wide temperature environments ranging from -25 ℃ to 70 ℃, as well as high humidity and dusty industrial scenarios.




ABB SPAJ140C overcurrent and ground fault relay

Basic characteristics of relays

The SPAJ140C relay is developed based on ABB's advanced power protection hardware platform, and its core features are concentrated in four advantages: "precise protection, fast response, flexible adaptation, and stable reliability". In terms of protection accuracy, a 32-bit high-performance microprocessor and a 16 bit high-precision A/D conversion module are used, with a current measurement accuracy of ± 0.5% and minimal fault diagnosis error, ensuring the accuracy of protection actions. In terms of response speed, for serious faults such as short circuits, the protection action time can be as low as 10ms, which can quickly cut off the circuit in the early stages of the fault, minimizing equipment damage and power outage range. In terms of adaptability, it supports multiple current transformer (CT) ratio configurations and is compatible with distribution lines of different capacities; It has rich communication interfaces and protection logic configuration functions, and can customize protection parameters according to different distribution scenarios. In terms of reliability, it adopts industrial grade wide temperature element devices and reinforced housing design, certified by the IEC 60255 series power relay standard, with an average time between failures (MTBF) of over 200000 hours, and can operate stably in wide temperature environments ranging from -25 ℃ to 70 ℃, as well as high humidity and dusty industrial scenarios.


Key technical parameters

current input

Three phase current: 0~5A AC (standard), supports CT transformation ratio of 1~10000/5A configuration; Zero sequence current: 0~5A AC; Remaining current: 0~1A AC (optional)

Voltage input (optional)

Three phase voltage: 0~100V AC (line voltage or phase voltage), frequency 50/60Hz adaptive

measurement accuracy

Current: ± 0.5% FS; Voltage: ± 0.5% FS; Power: ± 1.0% FS

Protection action time

Quick break protection: ≤ 10ms; limited time quick break protection: adjustable from 0.1 to 30s; Overcurrent protection: adjustable from 0.1 to 30s

Protection setting range

Overcurrent setting: 0.1~20Ie (Ie is the rated current); Grounding fault setting: 0.05~10Ie

communication interface

1 RS485 (supporting Modbus RTU); Optional 1 Ethernet port (supports IEC 61850)

Output contact

4 sets of normally open/normally closed optional contacts, contact capacity: AC 250V/5A, DC 24V/10A

power supply

DC 24V/48V/110V/220V or AC 110V/220V, power consumption ≤ 10W

working environment

Temperature: -25 ℃~70 ℃; Humidity: 5%~95% (no condensation); Protection level: IP40 (shell)

Installation method

DIN rail installation (35mm) or panel embedded installation

Overall dimensions

144mm (length) x 144mm (width) x 120mm (height) (panel installation); 100mm (length) x 80mm (width) x 120mm (height) (rail installation)

certification standard

IEC 60255-22-1 (Vibration), IEC 60255-22-2 (Impulse), IEC 60255-22-3 (ESD), IEC 61000-4-5 (Surge)


Applicable scenarios

The SPAJ140C overcurrent and ground fault relay is widely used in the power system and industrial distribution field due to its comprehensive protection function, high-precision measurement performance, and flexible adaptability. Typical scenarios include:

1. Protection of Industrial Enterprise Power Distribution System: In the power distribution network of industrial enterprises such as steel, chemical, and automobile manufacturing, relays are used to protect key equipment such as transformers, high-voltage motors, and distribution cables. In response to risks such as short circuits, overcurrent, and grounding faults that may occur during the production process, they quickly trigger protection actions to avoid production interruptions caused by equipment damage. For example, in the power supply circuit of reaction vessels in chemical enterprises, relays can achieve overcurrent protection and ground fault protection for motors, ensuring the safe operation of production equipment.

2. Protection of medium and low voltage substations: In the outgoing circuit of 10kV/0.4kV substations, relays serve as the core equipment for line protection, achieving three-stage overcurrent protection and grounding fault protection for distribution lines, and cooperating with the substation automation system to achieve rapid isolation of faults and power supply recovery. For example, when a single-phase grounding fault occurs in the outgoing line of a substation, the relay can accurately detect the zero sequence current, delay the triggering of the circuit breaker trip, and prevent the fault from expanding to the main transformer of the substation.

3. Protection of Building Electrical Systems: In the power distribution systems of large buildings such as commercial complexes, high-rise buildings, and data centers, relays are used to protect distribution circuits such as air conditioning units, water pumps, and lighting systems. They provide reliable protection against common issues such as overload, short circuit, and grounding faults in building electrical systems. At the same time, through remote communication functions, centralized monitoring and operation of building power distribution systems are achieved, improving the safety and management efficiency of building electrical systems.

4. New energy distribution network protection: In the collection lines and grid connected distribution circuits of photovoltaic power plants and wind farms, relays are used to protect the combiner boxes, inverters, grid connected switches and other equipment of the new energy power generation system. In response to the large fluctuations and complex fault types of new energy power generation, flexible configuration of protection parameters is used to achieve precise protection against overcurrent, grounding, overvoltage and other faults, ensuring the safe grid connected operation of the new energy power generation system.

5. Municipal public distribution protection: In the distribution system of municipal public facilities such as street lamps, sewage treatment plants, and rail transit, relays are used to protect distribution lines and electrical equipment, adapting to the dispersed and difficult operation and maintenance of municipal distribution scenarios. Through reliable protection functions and remote communication capabilities, they reduce the time of power outages, improve the power supply reliability of municipal public facilities, and ensure the normal operation of the city.


Precautions for use

-Before installing the relay, it is necessary to verify that the model, rated parameters (such as current input range, power supply), and distribution line specifications match. Check the appearance of the relay for damage and whether the wiring terminals are oxidized or loose; The installation location should be selected in a dry and ventilated area inside the distribution room, away from high-temperature heat sources (such as transformers and heaters), strong electromagnetic interference sources (such as high-voltage cabinets and frequency converters), and corrosive gases, to ensure good heat dissipation, avoid direct sunlight and rainwater splashing, and ensure sufficient operating and observation space during panel installation.

-Before wiring, the power supply of the distribution circuit and relay must be disconnected. The current input terminal, voltage input terminal, power terminal, communication terminal, and output contact terminal must be strictly distinguished according to the wiring manual. It is strictly prohibited to open the secondary side of the current transformer or short circuit the secondary side of the voltage transformer; The current circuit wiring must ensure correct phase to avoid protection misoperation caused by wiring errors; The signal line and power cable are laid separately, and the communication line adopts shielded twisted pair. The shielding layer is reliably grounded at one end (grounding resistance ≤ 4 Ω) to enhance anti-interference ability.

-Before the relay is put into operation, parameter configuration and functional testing need to be completed. CT transformation ratio, protection setting (current setting, action time), communication parameters, etc. can be set through local buttons or upper computer software. After configuration is completed, simulated fault testing is carried out. Simulated fault current and voltage signals are injected through the relay protection tester to verify the accuracy and timeliness of the protection action; At the same time, check whether the communication link is unobstructed to ensure that the parameters can be uploaded to the monitoring system normally.

-During operation, maintenance personnel need to regularly monitor the operating status through the relay local display screen or upper monitoring system, including real-time current and voltage parameters, protection function on/off status, communication status, etc; Check the tightness of the wiring terminals once a month to prevent loose connections caused by vibration; Clean the dust on the surface and installation area of the relay once a quarter to ensure smooth heat dissipation channels; Conduct a comprehensive functional verification once a year, retest the performance of protection actions, and update firmware versions in a timely manner.

-When a relay malfunctions and alarms, the fault information (such as fault type and parameters) should be queried through the local display screen or monitoring system to distinguish whether it is an equipment fault or a line fault. If it is a line fault, the relay should be manually reset after troubleshooting; If it is a hardware failure of the relay, it is necessary to power off and replace it with a relay of the same model. After replacement, import the backup parameter configuration to ensure that the protection function is consistent with the original equipment.

-Relay firmware upgrade requires obtaining genuine firmware that matches the model through ABB's official channels. Before upgrading, backup the current parameter configuration and event records. Power interruption is strictly prohibited during the upgrade process. After the upgrade is completed, restart the relay and perform functional verification; In areas with frequent thunderstorms, lightning surge protectors need to be installed on relay power supplies and communication interfaces to prevent equipment damage caused by lightning strikes; In humid environments, it is necessary to strengthen dehumidification in the distribution room to prevent damage to the internal components of the relay due to moisture.
