Emerson FloBoss ™ S600+ Flow Computer

Emerson FloBoss ™  S600+ Flow Computer

Product Overview

FloBoss ™  S600+is a panel mounted flow computer designed specifically for measuring hydrocarbon liquids and gases, emphasizing versatility and accuracy. It is an upgraded version of its predecessor S600 and is a market leading product of Emerson Process Management, suitable for various application scenarios such as flow measurement, trade handover, pipeline measurement, batch loading, instrument calibration, etc.

Core functions and features

Multi flow and multi station support: Supports multi flow (up to 10, optional expansion modules required) and multi station (up to 2) applications, can simultaneously measure gases, moisture, crude oil, refined products, LPG, NGL, etc., and can also accommodate liquid and gas stations simultaneously.

Wide compatibility: compatible with various flow meters or primary components, such as turbines, ultrasonic, Coriolis, positive displacement, orifice plates, Venturi, etc Annubar、V-Cone ®  And Rosemount adjustment orifice plate.

Global measurement standard support: Supports numerous global measurement standards, including AGA, ISO, GPA, GERG, etc. for gas applications, and API, ASTM, GPA, NORSOK, etc. for liquid applications.

High performance processing: adopting distributed processing, the main processor is more powerful, including hardware floating-point processors, with faster calculation speed. All metric calculations use 64 bit (double precision) floating-point numbers to ensure high precision and API compliance.

Data recording and archiving: The data recording and archiving capabilities have been significantly enhanced, including an extended historical recorder that can store 333 days of monthly, weekly, daily, and hourly reports for a typical 10 stream application, as well as 50000 events and 50000 alerts. Additionally, it supports FLOOCAL CFX files to enhance data integrity.

Convenient operation and display: Equipped with an 8-line LCD display screen and a 29 key keyboard, supporting English and Russian character sets, system parameters can be viewed or modified without the need for a PC.

Compatibility and Upgradeability: Fully backward compatible with the previous generation S600, it can utilize existing configurations and tools to facilitate upgrading the existing S600 to S600+, and the design ensures the future supply and support of the S600 series, with improved processing power and memory, and the ability to continuously add new features.

Technical parameters

CPU module: The processor is ColdFire ®  MPC8313 333 MHz， Equipped with an integrated floating-point processor; The operating system is Linux; In terms of memory, there are 256 MB of flash memory, 128 MB of DRAM, and 4 MB of SRAM (battery backup).

Battery: Lithium battery 3 V, 1400 mAh (CR12600SE), with a typical lifespan of 5-7 years, a battery free retention time of 18 months, and a backup retention time of 3 months at 20 ° C after battery failure.

Clock: Battery backed calendar clock with an accuracy of 0.5 seconds per day.

Input/output: Standard configuration includes 1 I/O (P144) module and 1 pulse mezzanine (P148) module, with the option to add 2 additional expansion modules, including I/O, Prover, HART, Pulse Mezzanine, and more; Analog input and output, digital input and output, pulse input and output each have corresponding types, ranges, accuracy and other parameters.

Power supply: Supply voltage 20-32 Vdc, nominal 30 Vdc, maximum 48 W; equipped with 2.5-A anti surge slow melting fuse, thermistor protection, three-way galvanic isolation, etc.

Physical parameters: The shell is a painted welded steel shell with a plastic front panel, and the front panel has a protection level of IP50; There are clear specifications for size, weight, etc; The display screen is a 128 x 64 pixel LCD with LED backlight, and the keyboard has 29 silicone rubber keys.

Environment and certification: Operating temperature -10 ° C to 55 ° C (14 ° F to 131 ° F), storage temperature -40 ° C to 70 ° C (-40 ° F to 158 ° F), relative humidity 90%, no condensation; Compliant with multiple EMC directives and standards, obtained multiple certifications such as MID and INMETRO.

Communication and Configuration

Communication options: Provides multiple communication interfaces, including 2 independent Ethernet 10/100baseT ports, optional 12 channel HART module supporting HART communication; Embedded web servers support remote access; 2 configurable EIA-232 (RS-232) serial ports; 7 EIA-422/485 (RS-422/RS-485) serial ports; USB 2.0 port; 1 dedicated configuration port.

Configuration tool: By using the same Windows based intelligent settings tool as S600 (Configura600 Lite, Configura600 Lite+, or Configura600 Pro) for configuration, multiple functions such as stream and station total, batch total, and recalculation can be achieved, and up to 20 different user configurations can be stored.

Application scenarios

Suitable for various scenarios in the energy and transportation fields, such as oil and gas pipeline measurement, trade handover measurement, batch loading control, instrument calibration, etc., it can meet the precise measurement and control needs of different media (gases, liquids, etc.).
